rinsed off with water immediately. Contact a physi-
cian.
• This appliance may be used by children aged 8 over
and by persons with reduced physical, sensory or
mental capabilities or lack of experience and know-
ledge, provided that they are under supervision or
have been told how to use the appliance safely and
are aware of the potential risks.
• Children must not play with the appliance.
• Cleaning and user maintenance tasks may not be
carried out by children unless they are supervised.
Attention - Property damage
• Use only accessories recommended by the manu-
facturer.
• The mains adapter may not be used for other pur-
poses.
• Always grip the power plug to disconnect the appli-
ance from the power supply.
• Do not place the appliance next to radiators, ovens
or other heated devices or surfaces.
• Always make certain that the ventilation slits are not
obstructed. A blocked ventilation circuit can result in
overheating and damage to the appliance.
• This product contains rechargeable batteries. Do
not throw the batteries into a fi re and do not subject
them to high temperatures. There is a risk of explo-
sion!
• Do not use the mains adapter for a diff erent product
and do not attempt to charge this appliance with a
diff erent mains adapter. Use only the mains adapter
supplied with this appliance.
• Never try to recharge non-rechargeable batteries.
Technical details
Charger
Input
Output
Protection Class
Appliance
Battery working voltage
Batteries
Operating time with full battery charge
Charging time for empty battery
Protection class
Before getting started
Assembly:
1.
Attach the suction attachment (1) to the connec-
tion (10) on the unit. Drive the suction attachment
(1) into the connection (10), so that unit and suc-
tion attachment are firmly attached to each other.
Ensure that the pins on the suction attachment
(1) are guided into the slots of the connection (1).
Fig.2
2.
Screw the wiper attachment with the spray nozzle
(5) onto the water container (7). Fig.3
3.
Attach the microfiber cover (6). Fig.4
12 І 24
www.scheppach.com service@scheppach.com +(49)-08223-4002-99 +(49)-08223-4002-58
Charging the battery (Fig.5)
You need to fully charge the battery before you use it
for the first time. The tool comes with a battery that is
not fully charged.
Note: Make sure that the unit is switched off before
you start charging it.
1.
2.
3.
4.
Rechargeable battery information
Recharge the battery only, when the suction power of
the tool is clearly reduced.
Start-up
Attention! Do not use any foaming, corrosive,
aggressive, abrasive or chemical cleaning agents.
Those can damage the device.
1.
2.
3.
4.
5.
6.
100 ~ 240 V
5 V
II
7.
3.6 V
Note: Keep working with the tool until the MAX level
Li-Ion
on the dirt water container (2) has been reached.
35 min
Turn off the tool and empty the container (2A). Open
2 h
the plug (14) at the bottom of the dirt water container.
(Fig.7). Empty the dirty water and close the dirt water
IPX4
container again. Now you can continue with your job.
8.
9.
Insert the plug (11) into the charging socket (12).
Plug the charging plug (9) into a socket.
The control light (4) flashes to show that charging
is in progress.
The control light (4) indicates by continuous illumi-
nation that the battery is charged.
Set the tip of the spray nozzle (13) to STREAM
(jet) or Spray (coarse water mist). (Fig.6)
Fill water into the spray bottle and add a
detergent, if needed, which is suitable for cleaning
windows.
Spray onto the area you want to clean.
With the microfiber cover (6) wipe across the
sprayed surface to loosen any stubborn dirt.
Turn on the unit by the I/O switch (3).
Move the squeegee of the suction attachment (1)
slowly from top to bottom over the wet surface.
The liquid is removed and sucked into the
container for dirt water (2).
Note: Do not move the squeegee sideways
across wet surfaces. The water will not be
absorbed and will thus run out of the squeegee by
the side.
After you have dried one track, start again from
the top pulling downwards.
If the whole surface is dry, press the I/O switch (3)
to turn the unit off. The control lamp (4) will turn
off.
If necessary, use a dry wipe to clean any streaks
or wet spots that may have been left on the
processed surface.
