In order to carry out a firmware uodate, connect your RMX-60 Digital via USB -58- to a computer and make sure that your RMX-60 Digital is
turned off via the ON/OFF Switch -57-. Activate the Firmware Update mode by pushing the Linfader start button -11- and the Crossfader start
button -13- down and powering your unit with the On/Off Power switch -57- on.
Plesae regularly check www. Reloop.com for RMX-60 Digital firmware updates. Please make sure that the loaded firmware is compatible with
your device.
1. Download the corresponding update package from the Reloop RMX-60 Digital product site and open it.
2. Open the program "ReloopFirmwareUpdate.jar".
3. Select the new firmware file by clicking "Open File" and selecting the
included *.bin file.
4. Click "Start >". The update will start now.
5. After a successful update turn off the Reloop RMX-60 Digital.
If you feel uncertain about this procedure, let your specialized dealer carry
out the update.
6. TECHNISCHE DATEN
Type: ................................................. Classic Club Mixer
Power supply: ................................. AC 100 – 240 V, 50/60 Hz
Dimensions: ..................................... 320 x 107.5 x 382.4 mm
Weight: ............................................. 6.8 kg
Inputs:
Line/CD: ........................................... 10k ohm / -14 dBV (200 mV)
Phono: .............................................. 47k ohm / -50 dBV (3.16 mV)
Aux: .................................................. 10k ohm / -14 dBV (200 mV)
Mic 1: ................................................. 6.8k ohm / -54 dBV (1.99 mV), unbalanced
Mic 2: ................................................ 6.8k ohm / -54 dBV (1.99 mV)
Outputs:
Master: ............................................. 1k ohm / 0 dBV (1 V) ±2 dB
Balanced: ......................................... 600 ohm / 0 dBV (1 V) ±2 dB
Booth: ............................................... 600 ohm / 0 dBV (1 V)
Rec: ................................................... 1k ohm / -10 dBV (316 mV) ±2 dB
Phones: ............................................ 33 ohm / -3 dBV (708 mV) ±2 dB
Frequency Range: .......................... 20 Hz – 20 kHz
Frequency Increase/Decrease: .... +12 dB / < -26 dB
S/N Ratio:
Phono: .............................................. 82 dB
Line: .................................................. 82 dB
Aux: .................................................. 90 dB
DJ Mic: ............................................. 90 dB
Mic 2 : ............................................... 90 dB
