7.2 Overload protection
Only available for the following: Item no. 2377930
■
Protects against overcurrent that can cause overheating.
■
When triggered the power supply to the sockets will be interrupted.
P :
RECONDITIONS
a
Overload protection has been triggered.
1. Switch the main power switch OFF (position "O").
2. Eliminate the condition(s) triggering the protection.
3. Wait approximately 5 – 10 minutes to allow the product to cool down.
4. Briefly press the reset button.
5. Switch the main power switch ON (position "I").
à
The product should be ready for use again.
8 Protection (USB ports)
8.1 Overload protection
Protects against overcurrent that can cause overheating.
■
When triggered the power supply to the port(s) will be interrupted.
■
The power supply will resume when the condition(s) triggering the protection are re-
moved.
8.2 Overcharge protection
Protects connected devices against overcharging.
■
Charging will stop when the connected device is fully charged.
■
Charging will resume when the connected device requires charging.
8.3 Short-circuit protection
Protects against overcurrent because of short circuit.
■
When triggered the power supply to the port(s) will be interrupted.
■
The power supply will resume when the condition(s) triggering the protection are re-
moved.
8.4 Over voltage protection
Protects connected devices against voltages exceeding the rated output.
■
When triggered the power supply to the port will be interrupted.
■
The power supply will resume when the condition(s) triggering the protection are re-
moved.
9 Cleaning and care
NOTICE! Do not use aggressive cleaning agents, rubbing alcohol or other chemical
solutions as they can cause damage to the housing and malfunctioning.
1. Disconnect the product from the power supply.
2. Clean the product with a dry, fibre-free cloth.
10 Disposal
Electronic devices are recyclable waste and must not be disposed of in the
household waste. At the end of its service life, dispose of the product in accord-
ance with applicable regulatory guidelines.
You thus fulfill your statutory obligations and contribute to the protection of the environment.
4

11 Technical data

11.1 General
Rated input .................................... 230 V/AC, 50 Hz, 16 A
Rated power .................................. max. 3680 W
Cable type ..................................... H05VV-F 3G1.5 mm²
Cable length .................................. 1.5 m
Enhanced protection against acci-
dental contact ................................ Yes
Socket controls.............................. Mains: ON/OFF
Protection (mains sockets) ............ SPD (surge protection device): Type 3 Uc 255 V/AC
Protection (USB ports)................... Overload, over voltage cut-off, short-circuit, over-
Cable management ....................... yes
Mounting possible.......................... yes
Operating conditions...................... -10 to +50 °C, 10 - 90 % RH (non-condensing)
Storage conditions......................... -10 to +50 °C, 10 - 90 % RH (non-condensing)
11.2 Model specific
Item no.: Consumers
2377929 10x mains, 2x USB-A
2377830 10x mains
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method (e.g. photocopying, microfilming or the capture in
electronic data processing systems) requires prior written approval from the editor. Reprinting, also in part, is prohibited.
This publication reflects the technical status at the time of printing.
Copyright by Conrad Electronic SE.
*2377929_2377930_V2_0821_dh_mh_en
USB (if applicable): always ON
(leakage current 12 kA)
Overload protection (only available for the following:
Item no. 2377930)
charge cut-off
Dimensions
(L x W x H)
698 x 69 x 51 mm
695 x 69 x 51 mm
Weight
974 g
955 g
