AVIRE 3G GSM Gateway Einbauanleitung Seite 5

Configuration check
To check configuration, send the following message to the 3G GSM:
Provided the sender is an authorised number then the following example will be received:
3#*1#3GLIFT#+447987654321,+447123456789#+447987654321,+447123456789
GSM status request message
Authorised numbers can request information about the GSM including signal level, power status, GSM firmware etc, by
sending the following message:
INFO
An SMS detailing the following information will be sent by the device:
• Device ID
• GSM Operator
• GSM Signal
• GSM Network info
• Battery Status (not used see next page)
• PCB Firmware
• GSM Firmware
• IMEI number
• Date and time
• Autotest SMS frequency and time
• List of Autotest SMS recipients
A full breakdown of the message is shown on the following page.
DEVICE REBOOT
Users can remotely reboot the device with the following message:
RESET
After the reception of the message, the device answers with an ACK message then will re-boot.
