Installing the MID meter

Electrical wiring

The MID meter should always be placed after the RCDs and MCBs on the charger's power line
(MID meter represented as position F on the installation diagram below).
A.
Grid
E.
Communication
H.
Other House Loads
B.
Utility Meter
C.
Main Switch
D.
Fuse Box
F.
RCDs+MCBs
G.
MID Meter
I.
Wallbox
Charger
J.
Car
