The assembly
1.
Remove the unit from its packaging and remove any packaging
materials from the unit and accessories. Especially the foam strips that
secure the tube during transport. Carefully pull them out of the unit in
the direction of the arrow.
In the event that you have carried out a function test before mounting the unit,
wait until the unit has cooled down before mounting it. wait until the unit has
cooled down before mounting it.
2.
Open your shade to which the spotlight is to be attached. The diameter
of the shade stand may be between 20 - 55 mm for the Ø55 version and
between 40 - 80 mm for the Ø80 version.
3.
Now take the O/U bracket out of the retaining ring by sliding it down.
Open the turning screw (1.) so far that the pressure plate is turned all
the way back.
4.
Now position the unit on the umbrella by sliding the bracket ring of the
spotlight with the O/U opening around the umbrella pole.
Attention: The side with the main switch and the markings I-III must
point downwards. The cable is then led out of the unit downwards!
5.
Now put the holder back into the ring and turn the turning screw in
until the spotlight sits firmly on the umbrella pole and is clamped secu
rely.
6.
Now you can adjust the height of the spotlight on the pole by
slightly opening and closing the turning screw. To do this, always hold
the spotlight with one hand so that the spotlight does not fall down.
7.
ATTENTION: Check the set height of the radiant heater under the um
brella so that the individual radiant heaters do not radiate directly
against the fabric of the umbrella with their radiation. This could heat
the fabric so much that it burns!
8.
Check that the angle of radiation is such that flammable objects under
the shade (for example on a table) cannot ignite. Safety distance of 1m
between the spotlight and objects!
GB
VASNER
17
