Improperly installed parts may lead to severe injury or death. Here recommends that all bike
assembly, tuning and repairs be performed by a qualified bicycle mechanic.
Figure 3.1
•
Use a Phillips or flat screwdriver to balance the brake adjustment.
•
Turn the screw clockwise on one arm to pull both arms in that direction.
•
In conjunction with adjusting the cable tension, adjust the screws so
each brake pad has 1-2mm clearance from rim.
•
Tuck the extra cable behind catch on the brake arm.
Figure 3.2
Balance Brake

Tuck-In Cable

15
