I. INSTALLATION INSTRUCTIONS

1. CONSTRUCTION

Top Panel
Separator
Door
Storage Bin
Air Filter
KM-40/60/80C-HC

2. ACCESSORIES

KM-40C-HC
KM-60C-HC
KM-80C-HC
Instruction Manual
Scoop
Leg
Power Supply Cord
(Continental)
Power Supply Cord (UK)
Pan Head Screw with
Washer (M4 x 30)
(louver fixing)
Thumbscrew (louver
fixing)
Spacer (M4) (louver
fixing)
Cleaning Pack Assy

3. UNPACKING

Children should not be allowed in reach of the packaging elements (plastic bags and expanded polystyrene) as they are
potential sources of danger.
Do not lift or manoeuvre the carton by using the shipping bands.
When moving the unit by hand, remove the louver and hold the unit bottom. Do not hold the top panel or door. It may come off
and cause injury.
Always wear protective gloves when carrying the unit.
When handling the carton or the unpacked unit, work in pairs to prevent injury.
Water Circuit
Control Box
Refrigeration
Circuit
Louver
KM-40C-HC-W
KM-140C-HC KM-60C-HC-W
KM-80C-HC-W
1 1 1
1 1 1
4 4 4
1 1 1
1 1 1
2 - -
- - 2
- - 2
- - 1
Top Panel
Separator
Door
Storage Bin
Air Filter
KM-140C-HC-W
1
Instruction Manual
1
4
1
1
-
Power Supply Cord
1
-
1
Thumbscrew
WARNING
CAUTION
3
ENGLISH
Water Circuit
Control Box
Refrigeration
Circuit
Louver
KM-140C-HC
Scoop
Pan Head Screw with Washer
Spacer Cleaning Pack Assy
Leg
