Li-Ion battery This product has been
marked with a symbol relating to 'separate
collection' for all battery packs and
battery pack. It will then be recycled or
Li-I on
dismantled in order to reduce the impact
on the environment. Battery packs can
be hazardous for the environment and for
human health since they contain hazardous
substances.
Do not burn
Batteries may enter water cycle if disposed
improperly, which can be hazardous for
ecosystem. Do not dispose of waste batteries
14
as unsorted municipal waste.
Make sure the battery is removed prior to
changing accessories

COMPONENT LIST

1. ON / OFF SWITCH
2. HAND GRIP AREA
3. BATTERY PACK *
4. BATTERY PACK RELEASE BUTTON*
5. SPINDLE LOCK BUTTON
6. SPINDLE
7. WHEEL GUARD FOR GRINDING
8. WHEEL GUARD FOR CUTTING
9. METAL CUTTING DISC
10. CLAMPING BOLT WITH WASHER
11. HEX KEY
12. ABRASIVE CUTTING DISC
13. GRINDING DISC
*Not all the accessories illustrated or described are
included in standard delivery.

TECHNICAL DATA

Type WX801 WX801.X (80 - designation of
machinery, representative of Angle grinder)
Rated voltage
Rated speed
Spindle thread
Thickness of metal cutting
disc
Thickness of abrasive cut-
ting disc
WX801 WX801.X***
20 V Max**
19500 rpm
M 6
1.2~1.4 mm
1.6 mm
