CAUTION, undesirable conse-
quences. The situation needs
operator awareness or action.
Well-ventilated. Always provide
proper ventilation during charging.
WARNING, explosive gases.
Lead-acid batteries generate
explosive gases during charging.
No open flame. Fire, open ignition
source and smoking are prohibited
near battery.
Introduction
This document contains use and maintenance
instructions for the intended battery charger.
This document is of relevance for the one who
uses the battery charger for its purpose; charge
batteries. It includes connecting the charger to the
battery, handling the charging process, and
managing basic settings.
Target groups:
Installers
Operators
Maintenance personnel and technicians
Receiving
On receipt, visually inspect the product for any
physical damage. If necessary, contact the
transport company.
Check the delivered parts against the delivery
note. Contact your supplier if something is
missing, see Contact information.
Installation

Mechanical installation

WARNING
Hot surface!
The battery charger will get hot during running. If
the battery charger is for a wheelchair or any help
vehicle, it must be mounted unreachable for the
user.
The battery charger:
is intended for installation in vehicles and
other applications,
is suitable for indoor and outdoor use,
is required to be mounted against a solid
surface,
should, when fitted on a wall or in a vehicle,
be vertically mounted for optimal cooling.
CAUTION
CAUTION
- Avoid high ambient
temperature, i.e. not near turbochargers, exhaust
manifolds, etc.

Electrical installation

WARNING
High voltage!
Incorrect connection of battery cables can cause
personal injuries and damage to the battery,
battery charger and cables.
Make sure the connections are correct.
WARNING
High voltage!
Risk of live chassis.
Always connect the charger to a power outlet with
protective earth.
1. The battery charger is produced for different
mains voltages. Check that the power supply
at the site of the installation complies with the
rated voltage specified on the battery charg-
er's data label. The label is located on the side
of the charger. The charger is normally equipp-
ed with fixed mains cable with connector.
2. Check the polarity of battery connector and
cable before connecting the battery. The
charger is normally delivered with a battery
cable with the following polarity:
Positive (+) = Red
Negative (−) = Blue or Black
3. Connect the battery cables to the battery.
ENGLISH
5
