7.1.2.1 Input Register Mapping - Neues Format

BeWa CSI-C-11 4548075a V250-V253 de web
Hier finden Sie das Mapping der Input Register des Modbus -
Neues Format.
CSI-C-11
Device ID (16 Zei-
chen)
8 Register mit je 2
Zeichen
Status Code
Error Code
Kanal 1 (32bit)
Kanal 2 (32bit)
Kanal 3 (32bit)
Kanal 4 (32bit)
Kanal 5 (32bit)
Kanal 6 (32bit)
Kanal 7 (32bit)
Kanal 8 (32bit)
Kanal 9 (32bit)
Input Register
0x0000 + Register Offset
0x0001 + Register Offset
0x0002 + Register Offset
0x0003 + Register Offset
0x0004 + Register Offset
0x0005 + Register Offset
0x0006 + Register Offset
0x0007 + Register Offset
0x0008 + Register Offset
0x0009 + Register Offset
0x000A + Register Offset
0x000B + Register Offset
0x000C + Register Offset
0x000D + Register Offset
0x000E + Register Offset
0x000F + Register Offset
0x0010 + Register Offset
0x0011 + Register Offset
0x0012 + Register Offset
0x0013+ Register Offset
0x0014 + Register Offset
0x0015 + Register Offset
0x0016 + Register Offset
0x0017 + Register Offset
0x0018 + Register Offset
0x0019 + Register Offset
0x001A + Register Offset
0x001B + Register Offset
Betrieb | 7
1
2
3
4
5
high byte
low byte
6
high byte
low byte
high byte
7
low byte
high byte
low byte
8
high byte
low byte
high byte
9
low byte
high byte
1
low byte
high byte
0
low byte
high byte
A
low byte
49 / 84
