Assembly TV stand:
Middle piece Screws
Back
Front
1. Place the TV set (A) on a flat and lightly padded surface with the display facing
downwards.
2. Screw the centre piece (B) to the TV set using the screws (C) supplied and a
screwdriver (not included).
3. Hold the stand foot (D) against the underside of the centre piece (C) and ensure that
it is correctly aligned (see PICTURE 2).
4. Screw the stand (D) to the TV with the screws (E).
PICTURE 1
A
Back view
C
PICTURE 2
D
TV-stand
E
TV- stand screws
45
B
Middle piece
EN
