Operation

General
Operating times
Please check noise abatement regulations prevailing in your
country.
Starter cord assembly K L
1. Lift and hold operator presence bail arm (K, 2).
2. Pull the starter rope slowly to the holding bracket.
3. Twist the cord through the holder (L).
lways remove the starter cord from the holder before
folding the mower handles.
Oil Fill M
Check oil level regulary before mowing!
To check, do not screw in the dipstick.
Fill crankcase with quality oil S E 30 up to the marking „Full"
on dipstick.Capacity approx. 0,6 litre . Lift mower slightly on the
oil filter side whilst pouring oil slowly.
Filling with Petrol
Do not smoke - no naked flames!
Switch off engine.
void spilling petrol when engine is warm.
Use „low-octane petrol" (do not use Super Plus).
void petrol spillage.
Do not inhale vapour.
Use of height adjustment N
Only when mower is stationary and rotating blade
has come to complete standstill.
Place hand into handle bar and depress button (1). Lift or
lower chassis until it engages into required position (2).
If possible, mow when grass is dry in order to protect turf.
Do not set cutting position too low when mowing very tall or wet
grass. We recommend an average cutting height of 4,0 - 5,0 cm.
Starting K L
1. Place mower on level ground, not on to high grass.
2. Throttle lever (K, 1) to "Betrieb" (= running).
3. Raise and hold safety grip (K, 2).
4. Premio 40 B i
Turn ignition key (K, 3) until engine starts, then release key.
Otherwise: Pull starter handle return slowly by hand (L).
Premio 40/46 B
Pull starter handle return slowly by hand (L).
5. Engine stop: Release safety grip (K, 2).
Switching wheel drive on/off K
Wheel drive on:
Lift drive bar (4).
Wheel drive off:
Release drive bar (4).
Selecting the speed (Vario)
1. Press button (5)
2. Use the lever (6) to select the desired working speed
(2.5 km/h - 5.0 km/h).
Rabbit: faster. Snail: slower.
Tips for mowing O
• To prevent strips of grass from being left unmowed, the
cutting paths must always overlap a few centimeters.
• lways turn the mower on a surface that has already been
mowed.
14
Mowing
ctivating the cut/ collect function (Power Edition 40) P
Make sure the motor is switched off and the
cutting blade is not moving.
• Turn the switch to „CUT/COLLECT".
Hanging the grass bag Q
Only when mower is stationary and rotating blade
has come to complete standstill.
1. Lift the protective flap.
2. Hang the grass bag in the chassis with the hooks in the
recesses (see arrow).
3. Replace the protective flap
Emptying the grass bag R
Only when mower is stationary and rotating blade
has come to complete standstill.
• When the grass bag is full, the flap lowers automatically.
• To ensure proper functioning: clean the holes beneath
the level indicator in the grass bag regularly with a hand
brush.
Mulching
„Mulching" is a process in which the grass is finely chop-
ped by a special cutting system and then deposited on the
ground. The result is that the grass does not have to be
collected and disposed of. „Mulching" also prevents the lawn
from drying out.
Note:
• Depending on how fast the grass grows, you should mulch
1-2 times each week.
• The grass should not be too high or very wet!
• Walk slowly.
• When cutting, the strips should overlap.
• Do not cut more than 20 cm of grass at a time.
Important!
„Mulching" is not recommended if the lawn is mossy or
matted.
Reason:
The cut grass remains on top fo the moss or matted grass
and cannot reach the ground below.
Remedy:
The lawn should be aerated and fertilized regularly.
ctivating the mulch function (Power Edition 40) P
Only when the motor is switched off and the
cutting blade is not moving.
1. Remove the grass collecting bag.
2. Set the switch to „MULCH".
Inserting the mulching kit (Power Edition 46)
Make sure that the motor is switched off and the
cutting blade is not moving.
1. Remove the grass bag.
2. ssemble as shown in illustrations
Disassemble: as shown in illustrations
F G
H J
