Fitting Instructions for MultiPod (all Versions)
Thank you for purchasing our product. There are many ways to
attach a MultiPod to a bike. It can be mounted directly to any
suitable accessible bolt, or alternatively with the flat bracket set,
Ø 22/29 mm bar clamps, adapter for free mirror mounts etc. (see page 8).
Order these alternative mounting systems separately.
Fitting of a "Long" version MultiPods (2 ball joints) to a bike:
1. The following instructions refer to fitting MultiPods to the handlebar mounts.
Remove a bolt, where the MultiPod is going to be fitted (Example Image A).
Preferably, this should be an 8mm diameter bolt. The bolt needed to attach
the MultiPod should have a shaft which is 20mm longer than the one removed.
If the optional "Extension Spacer" (Part. No. 1250288) is used, the new bolt
needs a 65mm longer shaft. Longer bolts can be ordered from your Wunderlich
dealer, see list on page 10.
2. Remove the lower ball joint of the MultiPod by loosening the wing nut (Image
B3) and the set screw (B4).
3. Insert the new (longer) bolt through the ball joint (Image C), and fit the
complete lower assembly to the bike. Images (D1 + 2) show the lower
attachment fitted to an R 1200 RT handle bar). NOTE: Please refer to the bike's
manufacturers recommendation for the torque values of the bolt, especially
important when this is a bolt related to the steering/handle bars! For BMW
motorcycles this value is usually 21-22 NM(15-16 ft/lb) for 8mm bolts.
4. Now attach the main body of the MultiPod to the lower part and lightly
tighten the wing nuts. If there are obstructions, each of the wing nuts can
be bolted on the opposite side of the MultioPod body: Remove the small set
screw (Image E1), screw in the wing nut (E2) instead and fit the set screw in
the free thread.
Fitting of a "Short" version MultiPod (1 ball joint) to a bike:
5. The "Short"-type MultiPod (only one ball joint on top) can be fitted to the
bike with our Flat Bracket (part no 1250295, Image K), a 22/29 mm bar clamp
(part. nos. 1250272/1250273, Image M) or onto any accessible position with
an 8mm bolt (Image L). Note: The "Short" type MultiPod is supplied with
an 8mm bolt and an adapter (for bar clamp etc.). Important: Make sure the
MultiPod does not impede movement of steering or touches other parts. If
needed, the wing nut can be bolted on the opposite side of the MultioPod
body: Remove the small set screw (Image E1), screw in the wing nut (E2)
instead and fit the set screw in the free thread.
