ENGLISH
HIGH LEVEL INPUT
IN 1 CHANNEL
FIRST SYSTEM START WITH APP (only with BT-D Upgrade) 1/2
IN+
IN– DIRECTION
D68SP
1 2 3 4 5 6
LEVEL
POWER
INPUT
POWER INPUT
AUTO TURN-ON
MIN MAX
IN 2
OFF DC VOX
+12V GND REM IN REM OUT MODE
OUT A OUT C OUT E OUT G
OUT B OUT D OUT F OUT H
OPTICAL IN
ESX DSP TOOLKIT APP:
App Store:
iOS™ smart phones and mobile devices
Google Play: Android™ smart phones and mobile devices
Download and install the ESX DSP TOOLKIT APP on your smart phone or mobile device
Connect the DSP device with your smart phone or mobile device via Bluetooth
The POWER LED lights up and after less than 10 seconds the device is operative
CAUTION
Before turning on the sound system, check again carefully the configuration of the crossovers
and the speakers setup. A wrong type of crossover or inappropriate parameters may cause perma-
nent damages on the speakers, especially on tweeters without passive crossovers.
26
IN 3 CHANNEL IN 5 CHANNEL
3/4 5/6
LEVEL LEVEL
INPUT INPUT
MIN MAX MIN MAX
IN 4 IN 6
BT
REMOTE
ANT
RESET
USB EXTENSION
Turn the ignition key to the ACC or ON position
Start the ESX DSP TOOLKIT APP
Select the model number of your DSP device
Setting the Speaker System
Setting the Input Configuration
Setting the Audio Parameters
Store the Setting in one of the 8 Presets
Wireless Bluetooth Connection
®
Device Name: ESX D68SP
Start
Bluetooth
®
®
