Network speed and network components
Please ensure that the upload speed of your Internet
connection is at least 0.5 Mbps. The user experience is
only as good as your network speed, network stability
and quality of your network components, such as
your Internet Router and WiFi access points or WiFi
repeaters. Please also make sure that your network
components are no older than two years old, have
been manufactured by a well-known manufacturer,
and have the latest firmware installed.
Should these requirements not be fulfilled, it may
occur, for example that the performance of audio and
video is poor or push notifications are delayed or do
not arrive on your smartphone or tablet at all.
Requirements:
High-speed Internet (via landline): DSL, cable or
optical fibre
Network: Ethernet, with DHCP
NOTES ON NETWORK CONNECTION
You can connect the device to the network using
a network cable. The connection via WiFi is not
possible!
Install a network cable (which is plugged into
a network switch / router with Internet access)
from the inside of your building to the assembly
location. The network cable between the assembly
location and the network switch / router can have
a maximum length of 80 m/262 ft (IEEE 802.3).
If you must span a distance of more than 80
meters/262 feet you can put a network switch in
between.
If you have only two wires available at
the assembly location, you may use the
"DoorBird 2-Wire Ethernet PoE Converter
A1071", sold separately. It allows you to
transfer network data (Ethernet) and
power (PoE) with a simple two-wire
cable over long distances. For example,
existing buildings with a simple two-wire
bell wire can be equipped with network
technology without having to retrofit any
network cables.
6
1
SWITCHING OFF POWER
Switch off the power to all wires leading to
the assembly location, i.e. the door chime,
electric door opener, power supply unit for
the video door station etc.
REMOVAL OF THE EXISTING
2
FRONT PANEL
Turn the safety screws counterclockwise until they
loosen.
Disconnect all cables from the main unit of your D202
or D201. Carefully remove the D201/D202 front panel
with the main unit from the mounting housing.
3
CONNECTING THE DEVICE
You can connect all necessary cables and wires to the
device now.
For easier installation we strongly
recommend to remove the plug from screw
connection terminal while you connect the
cables and wires.
Please remove any cables and wires from the
N OTICE
connection ports of the device that you do
not need.
