COMPONENTS*
1x Main Electrical Unit
with call button
and front panel
1x Power supply unit (mains adaptor) with four
country-specific adaptors
DEVICE
Front
1
2
3
4
5
1) Front panel
2) HDTV Video
3) Security screws
4) Light Sensor
For night-vision mode
5) Bluetooth transceiver
6) Speaker
7) Microphone
8) 4D Motion sensor
9) Illuminated call button with nameplate
VIDEOS
Need help with the installation? Be sure to
watch our installation videos which can be found
on http://www.doorbird.com/support
Each individual step of the installation is clearly
documented in the videos.
1x Installation manual
6
7
8
9
1x Quickstart guide
with Digital Passport
1x Screw connection
terminal plug
Inside
10
11
12
13
10) Diagnostic-LED
Lights up a few seconds after
connecting the device to power
11) Main Electrical Unit
12) Screw connection terminal
13) Gasket
INSTALLATION
All the steps below should be carried out carefully
by a competent adult, taking into consideration any
applicable safety regulations. Please contact us
directly or seek the advice of a competent specialist.
Please ensure that all wires used for the
installation are undamaged along their entire
length and approved for this type of use.
1x Waterproof A4 laser
printer paper for
labelling name plates
Small parts
