Lighting Technologies INOX LED 80 Montageanleitung Seite 2

Code Name
Kode Leuchtenbezeichnung
1997026250 INOX LED 80
1997025280 INOX LED 80
1997032240 INOX LED 80
Notes:
- CCT (in sphere) – correlated color temperature of luminaire's light which was measured in
integrating sphere
- Permissible deviation of parameters: power, luminous flux, weight from nominal values are
±10%.
- Permissible deviation of CCT value from nominal value is ±300К.
- The luminaries are designed for operation in АC 230 V, 50-60 Hz (±0.4 Hz) network.
- The supply mains must be protected from communication and electric impulse noise.
- The main characteristics of line voltages at a network user's supply terminals in public AC
electricity networks should comply EN 50160-2010.
- Luminous flux in emergency mode shown in %, is a percent of nominal value.
- Luminous flux flickeing <5%.
- Luminaire corresponds to the protection classification IP by IEC 60529.
- Diffuser type: Transparent protective glass.
- Maximum number of luminaries allowed per C16A circuit breaker - 18 pcs.
It is possible for power consumption to deviate more than ±10% from value stated in user
manual if ambient temperature is between -60°C to -40°C during first 20-30 minutes of
operation.
- Further information about luminaire's dimensions shown in the table, please see "Overall and
installation dimensions" section.
- All properties of luminaries are stated for nominal mains supply voltage and normal operating
conditions.
Notizen
- CCT (in the sphere) - Korrelierte Farbtemperatur der Strahlung der Lampe, gemessen in der
Ulbrichtkugel
- Die zulässige Abweichung der Werte: Leistung, Lichtstrom, Masse von den Sollwerten beträgt
±10%.
- Die zulässige Abweichung der CCT-Werte vom Sollwert beträgt ±300К.
- Die Leuchten sind für den Betrieb in АC 230 V, 50-60 Hz (±0.4 Hz) Netzwerk ausgelegt.
- Versorgungsnetze müssen vor Kommunikations- und elektrischen Impulsgeräuschen geschützt
werden.
- Die Netzqualität muss mit EN 50160-2010 übereinstimmen.
- Der Lichtstrom im Notfallmodus in% ist ein Prozent des Nennwerts.
Rated power, Power factor,
Execution W
Nennleistung
Ausführung , W
(GL/SS)
72
4000K /E/
(GL/SS)
82
5000K /E/
(PMMA/SS)
80
5000K /E/
2
**CCT (in
not less sphere)**, К
Leistungsfakt **CCT (auf
or, nicht dem Feld)**,
weniger К
4000
> 0,90
5000
> 0,98
Luminous
Luminous
efficiency,
flux, lm
lm/W
Lichtstrom, Lichtausbeut
lm e lm/W
8300 115
10000 122
3000 38
