Kapitel 5: Operation of CLI Management (englisch)
268
<range>: 1 to 24
Example:
GS-2124L(vlan)# enable sym-vlan 5-10
set mode
Syntax:
set mode <disable|port|tag|metro|double-tag> [up-link]
Description:
To switch VLAN mode, including disable, port-based, tag-based, metro
and double-tag modes.
Argument:
<disable>: vlan disable
<tag>: set tag-based vlan
<port>: set port-based vlan
<metro>: set metro mode vlan
<double-tag>: enable Q-in-Q function
<up-link>: syntax 1,5-7, available from 23 to 24, only for metro mode
vlan
Possible value:
<disable|port|tag|metro|double-tag>: disable,port,tag,metro,double-tag
[up-link]: 23 or 24 or "23,24"
Example:
GS-2124L(vlan)# set mode port
set port- group
Syntax:
set port-group <name> <range>
Description:
To add or edit a port-based VLAN group.
Argument:
<name>: port-vlan name
<range>: syntax 1,5-7, available from 1 to 24
Possible value:
<range>: 1 to 24
