ENGLISH

TECHNICAL SPECIFICATIONS

POWER SUPPLY
Operating Voltage:
Power Consumption:
Switched off:
Remote IN:
Remote OUT:
Fuse:
AUDIO STAGE
Distortion - THD+N (Digital Input):
Distortion - THD+N (Analog Input):
Bandwidth (–1 dB):
S/N Ratio @ A weighted (Digital Input):
S/N Ratio @ A weighted (Analog Input):
Input Sensitivity:
Input Impedance:
SIGNAL CONVERTERS
A/D:
D/A:
Crosstalk:
Output Voltage:

SIGNAL CONNECTIONS

8 x High Level Input with EPS via 16-pole Cable Adapter
6 x RCA Low Level Input
2 x RCA AUX Input
12 x RCA Pre-Output with 6.5 V RMS Max.
1 x Optical Input (PCM, 96 kHz / 24 bit)
1 x Coaxial Input (S/PDIF, 96 kHz / 24 bit)

Declaration of Conformity

Audio Design GmbH hereby declares that the MUSWAY TUNE12 device complies with
Directive 2014/53/EU. The full declaration of conformity can be viewed at www.musway.de/CE
2
8 V - 24 V RMS (High Level); 1 V - 8 V RMS (Low Level, AUX)
13 Ω (High Level); 22 kΩ (Low Level, AUX)
7 - 16 VDC (down to 6 V)
0.8 A
< 0.1 mA
3 - 16 VDC (1 mA)
11 - 15 VDC (300 mA)
3 A resettable
< 0.0005 %
< 0.004 %
15 Hz - 22 kHz
116 dB
108 dB
Burr-Brown 24 Bit / 96 kHz
Burr-Brown 24 Bit / 192 kHz
> 90 dB
6.5 V RMS
