CH1
CH3
CH5
CH2
CH4
CH6
LINE OUTPUT
9
BT
These RCA outputs deliver DSP modified low level preamplifier output signals for additional amplifiers.
Connect each channel according to your sound system setup.
USB
LINE INPUT (LOW LEVEL)
10
Connect here the preamplifier low level outputs coming from the head unit. The low level input on
TUNE12 can be use as an independent source, which means TUNE12 allows you to connect low level
input and high level input at the same time to use multiple source.
AUX IN
11
These stereo RCA inputs are suited for a auxiliary low level input signal from an external stereo pre-
amplifier source such as a game console or a media player.
INPUT SENSITIVITY
12
With these controllers you can adjust the input sensitivity for each input section. This function is suited
to match the output voltage of the connected signal source with the device.
CLIP
13
This LED lights up red if one of the 8 high level inputs (CH1-8) is overdriven. The LED has no func-
tion when an input signal is applied to the Optical input, Coaxial and the Bluetooth™ input. If this LED
lights up, reduce the input sensitivity by using the regarding controller Input Sensitivity until the LED
goes out.
CH7
CH9
CH11
CH8
CH10
CH12
LINE OUTPUT
9
DRC
OPTICAL
COAXIAL
INPUT
INPUT
+
CH1
CH1
CH3
CH5
L
CH2
CH4
CH6
R
LINE INPUT
10
TUNE 12
DIGITAL 12-CHANNEL
SIGNAL PROCESSOR
HI-LEVEL INPUT
-
-
-
-
+
-
-
-
CH8
+
CH2
+
CH3
+
CH4
CH5
+
CH6
+
CH7
+
12
SENSITIVITY
LINE.IN
AUX
HI.LEVEL
CH1-8
CH1-6
CLIP
Min
Max
Min
Max
Min
Max
13
AUX
11
POWER
REVERS REM OUT REM IN
+12V
GND
-
TURN ON SEL
REM
SPK
ENGLISH
9
