ENGLISH
TECHNICAL SPECIFICATIONS
POWER SUPPLY
Voltage:
Idle current:
Switched off:
Remote IN:
Remote OUT:
Fuse:
AUDIO STAGE
Distortion - THD (1 kHz @ 4 Ω, 90% Power):
Bandwidth (-3 dB, 6 V RMS, 4Ω):
S/N ratio @ A weighted, 1 V, Max. Power:
Input sensitivity:
Input impedance:
SIGNAL CONNECTIONS
6 x High Level Input with EPS via 12-pole Cable Adapter
6 x RCA Low Level Input
2 x RCA AUX Input
8 x RCA Pre-Output with 6.5 V RMS Max.
1 x Optical Input (PCM, 96 kHz / 24 bit)
Declaration of Conformity
Audio Design GmbH hereby declares that the MUSWAY DSP68 device complies with
Directive 2014/53/EU. The full declaration of conformity can be viewed at www.musway.de/CE
2
3 V - 21 V RMS (High Level); 1 V - 5 V RMS (Low Level)
13 Ω (High Level); 47 kΩ (Low Level)
7 - 15 VDC
0.5 A
<0.1 mA
9 - 15 VDC (1 mA)
11 - 15 VDC (200 mA)
3 A internal
0.05 %
15 Hz - 22 kHz
95 dB A
