Seite 1
EcoFlow DELTA Pro Smart Extra Battery User Manual...
Seite 3
Users take full responsibility for all usage and operations. Familiarize yourself with the related regulations in your area. You are solely responsible for being aware of all relevant regulations and using EcoFlow products in a way that is compliant.
1. Specifications General Info Net Weight Approximately 84lbs Dimensions 25x11.2x16.4in Capacity 3600Wh 48V Certification cTUVus CE FCC PSE KC RCM WEEE Input Port 3200W Max Extra Battery Port Input Output Port Extra Battery Port Output 45V-54V 4260W Max Battery Info Cell Chemistry Shelf Life 1 year (after a full charge)
5. Avoid using wires or other metal objects that may result in a short circuit. 6. Do not use unofficial components or accessories. If you need to replace any components or accessories, please visit official EcoFlow channels to check relevant information. 7. When using the product, please strictly follow the operating environment temperature specified in this user manual.
3.2 LCD Screen Remaining Charge / Discharge Time Remaining Battery Percentage Input Power Output Power Error Code Battery Failure Warning Extra Battery Indicator Overload Warning Low Temperature Warning High Temperature Warning Battery Level Indicator: The indicator will repeatedly fill while charging. If product is at 0% charge, the indicator will flash to warn you.
Seite 9
DELTA Pro and the Extra Battery. 2. After connecting the DELTA Pro EB to DELTA Pro, you need to make sure that the Extra Battery images appear on both the DELTA Pro and the Extra Battery screens. Charge or discharge the DELTA Pro EB after you have seen both images.
If the Alarm Prompt shows on the product LCD screen during use and does not disappear after a restart, please stop using it immediately (do not try to charge or discharge). If you require any other assitance, please contact EcoFlow Customer Service.
Do not store in temperatures above 113°F or below 14°F for an extended period. 2. Storing a battery with a low charge for a long period shortens its lifespan. DELTA Pro mitigates the damage by putting the battery into hibernation mode. To get the most out of the battery, make sure it is about 60% before putting DELTA Pro EB into long-term storage, and then once every three months, discharge the battery to 30% and recharge it back to 60%.
Seite 13
EcoFlow DELTA Pro Intelligenter Ersatzakku Benutzerhandbuch...
Produkt. Benutzer übernehmen die volle Verantwortung für Verwendung und Betrieb des Produkts. Machen Sie sich mit den entsprechenden Vorschriften in Ihrem Land vertraut. Sie sind allein dafür verantwortlich, alle relevanten Vorschriften zu kennen und EcoFlow-Produkte gemäß diesen Vorschriften zu verwenden. EcoFlow DELTA Pro (nachfolgend als DELTA Pro bezeichnet)
1. Spezifikationen Allgemeine Informationen Nettogewicht Etwa 84 Pfund (38 kg) Abmessungen 25 x 11,2 x 16,4 Zoll (63,5 x 28,5 x 41,7 cm) Kapazität 3600 Wh 48 V Zertifizierung cTUVus CE FCC PSE KC RCM WEEE Eingang 48 V 3200 W Max. Ersatzakku-Eingang Ausgang Ersatzakku-Ausgang 45 V–54 V 4260 W Max. Informationen zum Akku Zellenchemie Lagerung 1 Jahr (nach vollständiger Aufladung) Lebensdauer 3500 Zyklen bis 80 %+ Kapazität Umgebungsbetriebstemperatur...
6. Verwenden Sie nur Originalkomponenten oder -zubehörteile. Wenn Sie Komponenten oder Zubehör austauschen müssen, besuchen Sie bitte für alle relevanten Informationen die offiziellen EcoFlow- Kanäle. 7. Beachten Sie bei der Verwendung des Produkts unbedingt die in dieser Bedienungsanleitung angegebene Umgebungstemperatur.
3.2 LCD-Anzeige Verbleibende Lade-/Entladezeit Verbleibender Akkuladestand in Prozent Eingangsleistung Ausgangsleistung Fehlercode Warnung bei Akkuausfall Ersatzakku-Anzeige Überlastwarnung Warnung niedrige Temperatur Warnung hohe Temperatur Ladezustandsanzeige: Die Ladezustandsanzeige füllt sich während des Ladevorgangs wiederholt. Wenn das Produkt über einen Ladestand von 0 % verfügt, blinkt die Anzeige, um Sie zu warnen. * Weitere Schritte zur Fehlerbehebung finden Sie in Abschnitt 5.
Kapazitätsanforderungen zu erfüllen. Bitte lesen Sie vor der Verwendung die folgenden Hinweise sorgfältig durch: 1. Stellen Sie vor dem Anschließen des DELTA Pro und des DELTA Pro Ersatzakkus sicher, dass der DELTA Pro und der Ersatzakku nicht mit dem Strom verbunden sind.
Stellen Sie die Verwendung des Produkts umgehend ein, wenn die Alarmmeldung während des Betriebs auf der LCD-Anzeige angezeigt wird und nach einem Neustart nicht verschwindet (versuchen Sie nicht, das Produkt zu laden oder zu entladen). Wenn Sie weitere Unterstützung benötigen, wenden Sie sich bitte an den EcoFlow-Kundendienst.
6. Lieferumfang EcoFlow DELTA DELTA Pro Benutzerhandbuch Griffabdeckung Pro Intelligenter Ersatzakku-Kabel und Garantiekarte Ersatzakku 7. Lagerung und Wartung 1. Verwenden und lagern Sie das Produkt idealerweise zwischen 68 °F und 86 °F (zwischen 20 °C und 30 °C) und halten Sie es stets von Wasser, starker Hitze und scharfen Gegenständen fern. Lagern Sie das Produkt nicht längere Zeit in einer Umgebung, in der es Temperaturen über 113 °F (45 °C) oder...
Seite 25
Batterie intelligente supplémentaire EcoFlow DELTA Pro Manuel d'utilisation...
L'utilisateur assume l'entière responsabilité de l'utilisation et du fonctionnement du produit. Familiarisez-vous avec les réglementations en vigueur dans votre région. Il vous incombe de connaître toutes les réglementations pertinentes et d'utiliser les produits EcoFlow de manière conforme. EcoFlow DELTA Pro (ci-après nommé DELTA Pro)
Seite 28
TABLE DES MATIÈRES 1. Spécifications 2. Instructions de sécurité 2.1 Utilisation 2.2 Guide de mise au rebut 3. Pour commencer 3.1 Détails du produit 3.2 Écran LCD 3.3 Utilisation générale du produit 4. Foire aux questions 5. Dépannage 6. Contenu de la boîte 7. Stockage et entretien...
1. Spécifications Informations générales Poids net Environ 38 kg Dimensions 63,5 x 28,4 x 41,6 cm Capacité 3 600 Wh 48 V Certification cTUVus CE FCC PSE KC RCM WEEE Port d'entrée 48 V 3 200 W max Entrée de port de batterie supplémentaire Port de sortie Sortie de port de batterie supplémentaire 45 V-54 V 4 260 W max Informations relatives à...
5. Évitez d'utiliser des fils ou d'autres objets métalliques susceptibles de provoquer un court-circuit. 6. N'utilisez pas de composants ou d'accessoires non agréés. Si vous devez remplacer des composants ou des accessoires, consultez les ressources EcoFlow officielles pour vérifier les informations pertinentes.
3.2 Écran LCD Temps de charge/décharge restant Pourcentage de batterie restante Puissance d'entrée Puissance de sortie Code d'erreur Avertissement de défaillance de la batterie Indicateur de batterie supplémentaire Avertissement de surcharge Avertissement de température basse Avertissement de température élevée Indicateur de niveau de la batterie : l'indicateur se remplit de façon répétée pendant la charge. Si le produit est chargé...
Seite 33
À utiliser conjointement avec le modèle DELTA Pro La batterie supplémentaire DELTA Pro peut être utilisée avec une ou deux batteries DELTA Pro pour répondre à des exigences de capacité plus élevées. Veuillez lire attentivement les remarques suivantes avant l'utilisation : 1. Avant de raccorder le modèle DELTA Pro et la batterie supplémentaire, assurez-vous d'éteindre le modèle DELTA Pro et la batterie supplémentaire.
Si l'invite d'alarme s'affiche sur l'écran LCD du produit pendant l'utilisation et ne disparaît pas suite au redémarrage, cessez immédiatement de l'utiliser (n'essayez pas de le charger ou de le décharger). Si vous avez besoin d'aide, veuillez contacter le service client EcoFlow.
Couvercle de supplémentaire supplémentaire d'utilisation et poignée EcoFlow DELTA Pro DELTA Pro carte de garantie 7. Stockage et entretien 1. Idéalement, utilisez et conservez le produit entre 20 °C et 30 °C, et tenez-le toujours à l'écart de l'eau, de sources de chaleur intense et d'objets tranchants. N'entreposez pas le produit à des températures supérieures à...
Seite 37
Batteria supplementare dedicata EcoFlow DELTA Pro Manuale utente...
Gli utenti si assumono la piena responsabilità di tutti gli usi e le operazioni. Familiarizzare con le normative in vigore nella propria zona. L'utente è l'unico responsabile della conoscenza di tutte le normative pertinenti e dell'uso conforme dei prodotti EcoFlow. EcoFlow DELTA Pro (di seguito denominato DELTA Pro)
Seite 40
CONTENUTO 1. Specifiche 2. Istruzioni per la sicurezza 2.1 Uso 2.2 Guida allo smaltimento 3. Guida introduttiva 3.1 Dettagli sul prodotto 3.2 Schermo LCD 3.3 Uso generale del prodotto 4. DOMANDE FREQUENTI 5. Risoluzione dei problemi 6. Contenuto della confezione 7.
Seite 41
1. Specifiche Informazioni generali Peso netto Circa 84 lb (38,10 kg) Dimensioni 25x11,2x16,4 in (63,5x28,5x41,66 cm) Capacità 3600 Wh, 48 V Certificazione cTUVus CE FCC PSE KC RCM WEEE Porta di ingresso 48 V 3200 W max Ingresso porta batteria supplementare Porta di uscita Uscita porta batteria supplementare 45 V-54 V...
6. Non utilizzare componenti o accessori non autorizzati. In caso sia necessario sostituire un componente o un accessorio, verificare le istruzioni pertinenti sui canali ufficiali di EcoFlow. 7. Quando si utilizza il prodotto, attenersi rigorosamente alla temperatura dell'ambiente di esercizio specificata nel presente manuale dell'utente.
3.2 Schermo LCD Tempo di carica/scarica rimanente Percentuale rimanente della batteria Alimentazione in ingresso Alimentazione in uscita Codice di errore Avviso di guasto della batteria Indicatore batteria supplementare Avviso di sovraccarico Avviso di bassa temperatura Avviso di temperatura elevata Indicatore del livello della batteria: l'indicatore si riempie ripetutamente durante la carica. Se il prodotto è allo 0% di carica, l'indicatore lampeggia per avvisare l'utente.
Seite 45
Caricare o scaricare DELTA Pro EB dopo aver visualizzato entrambe le icone. 3. NON collegare DELTA Pro EB al DELTA Pro durante la scarica o la carica; se è necessario rimuovere il cavo della batteria supplementare, accertarsi che DELTA Pro EB e DELTA Pro siano entrambi spenti.
Se la richiesta di allarme viene visualizzata sullo schermo LCD del prodotto durante l'uso e non scompare dopo un riavvio, interromperne immediatamente l'utilizzo (non tentare di caricarlo o scaricarlo). Se è necessaria ulteriore assistenza, contattare il servizio clienti EcoFlow.
Per ottenere il massimo dalla batteria, assicurarsi che essa sia circa al 60% prima di mettere via DELTA Pro EB per lungo tempo, quindi, una volta ogni tre mesi, scaricare la batteria al 30% e ricaricarla fino al 60%.
Seite 49
Batería adicional inteligente EcoFlow DELTA Pro Manual de usuario...
Los usuarios son totalmente responsables del uso y las operaciones. Familiarícese con la normativa en vigor en su zona. Usted es el único responsable de conocer todas las normativas vigentes y de usar los productos EcoFlow de conformidad con ellas. EcoFlow DELTA Pro (en lo sucesivo, DELTA Pro)
Seite 52
ÍNDICE 1. Especificaciones 2. Instrucciones de seguridad 2.1 Uso 2.2 Guía de eliminación 3. Primeros pasos 3.1 Detalles del producto 3.2 Pantalla LCD 3.3 Uso general del producto 4. Preguntas frecuentes 5. Solución de problemas 6. Contenido de la caja 7.
1. Especificaciones Información general Peso neto Aproximadamente 84 lb (38,1 kg) Dimensiones 25 x 11,2 x 16,4 pulgadas (63,5 x 28,4 x 41,6 cm) Capacidad 3600 Wh, 48 V Certificación cTUVus CE FCC PSE KC RCM WEEE Puerto de entrada 48 V 3200 W máx. Entrada de la batería adicional Puerto de salida Salida de la batería adicional 45 V-54 V...
5. Evite el uso de cables u otros objetos metálicos que puedan provocar un cortocircuito. 6. No utilice componentes ni accesorios no oficiales. Si necesita sustituir algún componente o accesorio, visite los canales oficiales de EcoFlow para comprobar la información pertinente. 7. Cuando utilice el producto, respete estrictamente la temperatura ambiente de funcionamiento que se indica en este manual de usuario.
3.2 Pantalla LCD Tiempo de carga/descarga restante Porcentaje de batería restante Alimentación de entrada Alimentación de salida Código de error Advertencia de fallo de la batería Indicador de batería adicional Advertencia de sobrecarga Advertencia de baja temperatura Advertencia de alta temperatura Indicador de nivel de la batería: el indicador se llena repetidamente durante la carga.
Seite 57
Para su uso junto con DELTA Pro La batería adicional DELTA Pro se puede utilizar con uno o dos DELTA Pro para cumplir con los requisitos de capacidad máxima. Lea atentamente las siguientes notas antes de usar el producto: 1. Antes de conectar DELTA Pro y la batería adicional, asegúrese de que ambos dispositivos estén apagados.
Si el indicador de alarma aparece en la pantalla LCD del producto durante su uso y no desaparece después de reiniciarlo, deje de usarlo inmediatamente (no intente cargarlo ni descargarlo). Si necesita más ayuda, póngase en contacto con el servicio de atención al cliente de EcoFlow.
2. Almacenar una batería con una carga baja durante un largo periodo de tiempo reduce su vida útil. DELTA Pro mitiga los daños poniendo la batería en modo de hibernación. Para sacarle el máximo partido a la batería adicional DELTA Pro, asegúrese de que tiene una carga del 60 % aproximadamente antes de almacenarla durante un periodo de tiempo prolongado y, una vez cada tres meses, descargue la batería al 30 % y recárguela al 60 %.
Seite 61
EcoFlow DELTA Pro Smart Extra Batterij Gebruikershandleiding...
Seite 63
U bent er als enige verantwoordelijk voor dat u op de hoogte bent van alle relevante voorschriften en dat u EcoFlow-producten gebruikt op een manier die aan de voorschriften voldoet. EcoFlow DELTA Pro (Hierna aangeduid als DELTA Pro)
Seite 64
INHOUD 1. Specificaties 2. Veiligheidsinstructies 2.1 Gebruik 2.2 Verwijderingsgids 3. Aan de slag 3.1 Productgegevens 3.2 LCD-scherm 3.3 Algemeen gebruik product 4. Veelgestelde vragen 5. Problemen oplossen 6. Inhoud van de doos 7. Opslag en onderhoud...
1. Specificaties Algemene info Nettogewicht Ongeveer 84 lbs (38 kg) Afmetingen 25x11,2x16,4 in Capaciteit 3600 Wh 48 V Certificering cTUVus CE FCC PSE KC RCM WEEE Invoerpoort 48 V 8 A, 3200 W max Invoer van poort Extra Batterij Uitvoerpoort Uitvoer van poort Extra Batterij 45 V-54 V 4260 W max...
6. Gebruik geen onderdelen of accessoires van derden. Als u onderdelen of accessoires moet vervangen, ga dan naar de officiële EcoFlow-kanalen voor relevante informatie. 7. Houd u bij het gebruik van het product strikt aan de omgevingstemperatuur voor gebruik dat in deze gebruiksaanwijzing wordt vermeld.
3.2 LCD-scherm Resterende oplaad-/ontlaadtijd Resterend batterijpercentage Ingangsvermogen Uitgangsvermogen Foutcode Waarschuwing batterijstoring Indicator extra batterij Waarschuwing overbelasting Waarschuwing lage temperatuur Waarschuwing hoge temperatuur Indicator batterijniveau: De indicator wordt herhaaldelijk gevuld tijdens het opladen. Als het product 0% is opgeladen, knippert het lampje om u te waarschuwen. * Zie Sectie 5 voor meer stappen voor probleemoplossing.
Seite 69
Lees de volgende punten zorgvuldig door voordat u het apparaat gebruikt: 1. Voordat u verbinding maakt met de DELTA Pro en de Extra Batterij, moet u de DELTA Pro en de Extra Batterij uitschakelen. 2. Nadat u de DELTA Pro Extra Batterij hebt aangesloten op de DELTA Pro, moet u ervoor zorgen dat de pictogrammen Extra Batterij worden weergegeven op zowel de schermen van de DELTA Pro als die van de Extra Batterij.
Als de Alarmmelding tijdens het gebruik op het LCD-scherm van het product wordt weergegeven en niet verdwijnt na het opnieuw opstarten, stop dan onmiddellijk met het gebruik (probeer niet op te laden of te ontladen). Neem contact op met de klantenservice van EcoFlow als u andere ondersteuning nodig hebt.
Pro beperkt de schade door de batterij in de slaapstand te zetten. Om het maximale uit de batterij te halen, moet u ervoor zorgen dat deze ongeveer 60% is opgeladen voordat u DELTA Pro Extra Batterij in langdurige opslag plaatst. Vervolgens moet u de batterij elke drie maanden ontladen tot 30% en...
Seite 73
Дополнительный интеллектуальный аккумулятор EcoFlow DELTA Pro Руководство пользователя...
Seite 75
Пользователи несут полную ответственность за эксплуатацию и выполняемые операции. Ознакомьтесь с применимыми нормами законодательства, действующими в вашем регионе. Пользователь несет единоличную ответственность за ознакомление со всеми соответствующими нормами и их соблюдение при использовании продукции EcoFlow. EcoFlow DELTA Pro (далее DELTA Pro)
Seite 76
СОДЕРЖАНИЕ 1. Технические характеристики 2. Техника безопасности 2.1 Эксплуатация 2.2 Инструкции по утилизации 3. Начало работы 3.1 Описание устройства 3.2 ЖК-экран 3.3 Общие правила эксплуатации 4. ЧАСТО ЗАДАВАЕМЫЕ ВОПРОСЫ 5. Поиск и устранение неисправностей 6. Комплект поставки 7. Хранение и обслуживание...
1. Технические характеристики Общие сведения Масса нетто Приблизительно 84 фунта (38,1 кг) Размеры 25x11,2x16,4 дюйма (63,5х28,5х41,6 см) Емкость 3600 Втч 48 В Сертификаты cTUVus CE FCC PSE KC RCM WEEE Входной порт 48 В 3200 Вт макс. Входной порт дополнительного аккумулятора Выходной...
6. Не используйте компоненты или принадлежности от неофициальных производителей. Если необходимо заменить компонент или принадлежность, уточните информацию по официальным каналам EcoFlow. 7. При работе с устройством строго соблюдайте требования по температуре рабочей среды, указанные в настоящем руководстве. При слишком высокой температуре среды возникает риск пожара или...
3.2 ЖК-экран Оставшийся заряд / Время разрядки Оставшийся заряд в процентах Потребляемая мощность Выходная мощность Код ошибки Предупреждение об отказе аккумулятора Индикатор дополнительного Предупреждение о перегрузке аккумулятора Предупреждение о переохлаждении Предупреждение о перегреве Индикатор уровня заряда аккумуляторной батареи: Во время зарядки индикатор будет неоднократно заполняться.
Seite 81
Для использования вместе с DELTA Pro Дополнительный аккумулятор DELTA Pro может использоваться с одним или двумя DELTA Pro для соответствия более высоким требованиям к емкости. Перед использованием внимательно прочтите следующие инструкции: 1. Перед подключением DELTA Pro и дополнительного аккумулятора убедитесь, что DELTA Pro и...
Значок продолжает Свяжитесь со службой поддержки Отказ аккумулятора гореть EcoFlow Если в процессе использования на ЖК-экране аккумулятора отображается аварийное сообщение, которое не исчезает после перезагрузки, немедленно прекратите использование (не пытайтесь зарядить или разрядить устройство). За консультациями обращайтесь в службу поддержки EcoFlow.
службы. DELTA Pro снижает ущерб, переводя аккумулятор в режим пониженного энергопотребления. Чтобы максимально эффективно использовать аккумулятор, убедитесь, что уровень его заряда около 60%, прежде чем помещать дополнительный аккумулятор DELTA Pro на длительное хранение, а затем раз в три месяца разряжайте аккумулятор до 30% и снова заряжайте до 60%.
Seite 93
使用前, 請仔細閱讀以下注意事項: 1. 將 DELTA Pro 與加電包連接前, 請確保已關閉 DELTA Pro 和加電包。 2. 將 DELTA Pro 加電包與 DELTA Pro 連接後, 須確保 DELTA Pro 和加電包的顯示器上均顯示加電包圖示。 顯示兩 個圖示後, 為 DELTA Pro 加電包充電或放電。 3. 請勿在放電或充電時將 DELTA Pro 加電包與 DELTA Pro 連接; 如須拔除加電包連接線, 請確保 DELTA Pro 加電...
