Quick Start Guide XG 210 Rev. 3, XG 230 Rev. 2
d) Device LED Status
Power (LED Display)
Power Supply Acitve Green
Power Supply Failure Red
SSD Active Blue
LEDs on each RJ45 Ethernet connector
ACT/LNK Green Constantly
(Left LED)
Flashing
Off
Speed Amber On
(Right LED)
Green On
Off
LEDs on each SFP connector
ACT/LNK Green Constantly
Flashing
Off
1. The Ethernet port is receiving power.
2. Good connection between the Ethernet port and hub.
The adapter is sending or receiving network data. The
frequency of the flashes varies with the amount of traffic.
1. The adapter and switch are not receiving power.
2. No connection between both ends of network.
3. Network drivers have not been loaded
or do not function correctly.
The Ethernet port is operating at 1,000 Mbps.
The Ethernet port is operating at 100 Mbps.
The Ethernet port is operating at 10 Mbps.
1. The SFP connector is receiving power.
2. Good linkage between the SFP connector and hub.
The adapter is sending or receiving network data. The
frequency of the flashes varies with the amount of traffic.
1. The adapter and switch are not receiving power.
2. No connection between both ends of network.
3. Network drivers have not been loaded
or do not function correctly.
