5. Disposal
This product should be disposed of in accordance with local regulations.
If you are unsure how to proceed, contact your local council.

6. Troubleshooting

Problem
Fails to split log.
Pressure plate moves jerkily,
makes strange noises and
vibrates heavily.
Oil leak around piston or
other component.

7. Specifications

Motor voltage
Power
IP rating
Log capacity*
Rec operating temp
Splitting force
Oil pressure
Oil capacity
Dimensions
Weight
Adjustable return stop
* The stated splitting capacity is indicative and depends on the hardness, diameter and knottiness of the wood.
It is usually possible to split far larger diameter logs.
Possible cause
Log improperly positioned.
The log is too big or too hard.
The wedge is blunt or damaged.
Oil leakage.
Incorrect pressure limiting screw
setting.
Lack of oil, air in the system.
Air trapped in system during
operation.
The bleed screw has not been tight ened
before the log splitter was moved.
The oil drain bolt is not properly tight.
The hydraulic valve and/or gasket is worn.
230 V AC, 50 Hz
2200 W
IP54
Ø 5–25 cm, length: 25–52 cm
+5 °C to + 40 °C
5 tonnes
20 Mpa
3.5 litres
Length: 1000 mm
Width: 360 mm
Height: 450 mm
45 kg
160–520 mm
9
Remedy
Turn the log around or rotate it.
Reduce the size of the log before splitting.
Sharpen the wedge
(refer to Maintenance).
Localise the leak, have a qualified
mechanic fix the leak.
Have a qualified mechanic adjust
the pressure setting.
Check the oil level and refill if necessary.
Check for leaks.
Loosen the bleed screw 3–4 turns
before starting work.
Tighten the bleed screw before moving
the log splitter.
Tighten the oil drain bolt.
Contact the retailer.
