2. Product description

2
1
13 12
B 14
Parts
1. Control lever
2. Control lever guard
3. Pressure plate
4. Support table
5. Log retaining plate
6. Splitting wedge
7. Bleed screw
8. Oil drain bolt/dipstick
9. Return stop
10. Support leg
11. Power switch
12. Electrics box
13. Motor
14. Wheels for short range transport only
15. Handle
3 4 5
A
11
C

Package contents

A) Log splitter
B) Wheels
C) Instruction manual
D) Bag of assorted fasteners
E) Handle
