5.1. Hardware Description

1). SF200 Body description see Fig 2. :
2). LED status :
SYMBOL
Bluetooth
Bluetooth GPS Receiver
Downloaded from www.Manualslib.com
LED of GPS
(Orange)
COLOR
Blue Blinking
Red Light on
Green Light on
Battery
N/A Light off
Light on
Orange Blinking
GPS
manuals search engine
Power Switch
(Fig.2)
STATUS
1 time / 1 sec Search Bluetooth Device
1 time / 1 sec Standby Mode
1 time / 3 sec Transferring Data
Power too low
In charging
Battery full or Not in charging
Acquiring Satellites
Position Fixed
9
MSI SF200
LED of Battery
(Red / Green)
Bluetooth LED
(Blue)
Power Jack
DESCRIPTION
