Part-List; Description - Jet-Line group SUNRAY Montage- & Bedienungsanleitung

1. PART-LIST

All models of the type „Sunshade" contain the following parts:
No.

Description

1 Awning
Bracket with hexagon
2
head bolt and locknut
Wall anchor with locknut,
3
washer and locking ring
4 Remote Control
Installation and
5
User Manual
Motor Limit Stop
6
Adjusting Pole
2. DESCRIPTION
Drawing
1.Front Bar
2.Fabric
3.Bracket
4.Upper Cover
5.Side-Cover
Pcs.
4 Meter
1x
3x
12x
1x
1x
1x
6.Folding Arm
7.Arm Shoulder
8.Lower Cover
9.Roller
10.Power Cord
Pcs.
5 Meter
1x
3x
12x
1x
1x
1x
