ASROCK H610M-HDV Bedienungsanleitung
  1. Anleitungen
  2. Marken
  3. ASROCK Anleitungen
  4. Mainboards
  5. H610M-HDV
  6. Bedienungsanleitung
ASROCK H610M-HDV Bedienungsanleitung

ASROCK H610M-HDV Bedienungsanleitung

Vorschau ausblenden
Inhaltsverzeichnis

Werbung

Verfügbare Sprachen
  • DE

Verfügbare Sprachen

  • DEUTSCH, seite 25

Quicklinks

Diese Anleitung herunterladen
Version 1.0
Published December 2021
Copyright©2021 ASRock INC. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Inc.
Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identification or explanation and to the owners' benefit, without intent to
infringe.
Disclaimer:
Specifications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock. ASRock assumes no responsibility for
any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or fitness for a particular
purpose.
In no event shall ASRock, its directors, officers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of profits, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from any
defect or error in the documentation or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
"Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate"
ASRock Website: http://www.asrock.com

Werbung

Inhaltsverzeichnis
loading

Verwandte Anleitungen für ASROCK H610M-HDV

Inhaltszusammenfassung für ASROCK H610M-HDV

  • Seite 1 (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Seite 2 If you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard International call charges apply) The terms HDMI®...
  • Seite 3 ES OF ANY KIND WHETHER UNDER THIS AGREEMENT OR OTHERWISE, EVEN IF INTEL HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. LICENSE TO USE COMMENTS AND SUGGESTIONS. This Agreement does NOT obligate Licensee to provide Intel with comments or suggestions regarding the Software. However, if Licensee provides Intel with comments or suggestions for the modification, correction, improvement or enhancement of (a) the Software or (b) Intel products or processes that work with the Software, Licensee grants to Intel a non-exclusive, worldwide,...
  • Seite 5 H610M-HDV H610M-HVS Motherboard Layout H610M-HDV:...
  • Seite 6 H610M-HVS:...
  • Seite 7 H610M-HDV H610M-HVS No. Description ATX 12V Power Connector (ATX12V1) CPU Fan Connector (CPU_FAN1) 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1) Chassis/Water Pump Fan Connector (CHA_FAN1/WP) ATX Power Connector (ATXPWR1) USB 3.2 Gen1 Header (USB3_3_4) USB 2.0 Header (USB_5_6) SATA3 Connector (SATA3_2) (Upper), SATA3 Connector (SATA3_3) (Lower)
  • Seite 8 I/O Panel H610M-HDV: No. Description No. Description USB 2.0 Ports (USB_1_2) USB 3.2 Gen1 Ports (USB3_1_2) LAN RJ-45 Port* PS/2 Mouse/Keyboard Port Line In (Light Blue)** HDMI Port Front Speaker (Lime)** D-Sub Port Microphone (Pink)** DisplayPort 1.4 USB 2.0 Ports (USB_3_4) H610M-HVS: No.
  • Seite 9 H610M-HDV H610M-HVS * There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port Activity / Link LED Speed LED Status Description Status Description No Link...

  • Seite 10: Package Contents

    ASRock’s website without further notice. If you require technical support related to this motherboard, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.
  • Seite 11 • Dual Channel DDR4 Memory Technology • 2 x DDR4 DIMM Slots • Supports DDR4 non-ECC, un-buffered memory up to 3200* * Please refer to Memory Support List on ASRock's website for more information. (http://www.asrock.com/) • Supports ECC UDIMM memory modules (operate in non- ECC mode) • Max.
  • Seite 12 • 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) • HD Audio Jacks: Line in / Front Speaker / Microphone H610M-HDV: • 1 x D-Sub Port • 1 x HDMI Port • 1 x DisplayPort 1.4 H610M-HVS: • 1 x D-Sub Port...

  • Seite 13: Hardware Monitor

    H610M-HDV H610M-HVS Connector • 1 x SPI TPM Header • 1 x Chassis Intrusion and Speaker Header • 1 x CPU Fan Connector (4-pin) * The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. • 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan...
  • Seite 14 * For detailed product information, please visit our website: http://www.asrock.com Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools. Overclocking may affect your system’s stability, or even cause damage to the components and devices of your system.

  • Seite 15: Installing The Cpu

    H610M-HDV H610M-HVS 2.1 Installing the CPU 1. Before you insert the 1700-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket.
  • Seite 16 Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.
  • Seite 17 H610M-HDV H610M-HVS 2.2 Installing the CPU Fan and Heatsink...
  • Seite 18 2.3 Installing Memory Modules (DIMM) This motherboard provides two 288-pin DDR4 (Double Data Rate 4) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR4 DIMM pairs. 2.
  • Seite 19 H610M-HDV H610M-HVS 2.4 Expansion Slots (PCIe Slots) There are 2 PCIe slots on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.
  • Seite 20 2.5 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper (CLRMOS1) 2-pin Jumper (see p.1, 2, No.
  • Seite 21 H610M-HDV H610M-HVS 2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header...
  • Seite 22 Serial ATA3 Connectors These four SATA3 Right Angle: connectors support SATA (SATA3_2: data cables for internal see p.1, 2, No. 8) (Upper) storage devices with up to 6.0 (SATA3_3: Gb/s data transfer rate. see p.1, 2, No. 8) (Lower) Vertical: (SATA3_0: see p.1, 2, No.
  • Seite 23 H610M-HDV H610M-HVS Chassis/Water Pump Fan This motherboard provides 4 3 2 1 Connector a 4-Pin water cooling chassis (4-pin CHA_FAN1/WP) fan connector. If you plan to FAN_SPEED_CONTROL CHA_FAN_SPEED (see p.1, 2, No. 4) connect a 3-Pin chassis water FAN_VOLTAGE cooler fan, please connect it to Pin 1-3.
  • Seite 24 SPI TPM Header This connector supports SPI SPI_DQ3 SPI_PWR (13-pin SPI_TPM_J1) Trusted Platform Module (TPM) Dummy SPI_MOSI (see p.1, 2, No. 13) system, which can securely store RST# TPM_PIRQ keys, digital certificates, passwords, and data. A TPM system also helps SPI_TPM_CS# enhance network security, protects RSMRST#...

  • Seite 25: Technische Daten

    • Dualkanal-DDR4-Speichertechnologie • 2 x DDR4-DIMM-Steckplätze • Unterstützt ungepufferten DDR4-Non-ECC-Speicher bis 3200* * Weitere Informationen finden Sie in der Speicherkompatibilitätsliste auf der ASRock-Webseite. (http://www.asrock.com/) • Unterstützt ECC-UDIMM-Speichermodule (Betrieb im non-ECC- Modus) • Systemspeicher, max. Kapazität: 64GB • Unterstützt Intel® Extreme Memory Profile (XMP) 2.0 • 1 x PCIe-Gen4x16-Steckplätze*...
  • Seite 26 • 4 x USB-2.0-Ports (unterstützt Schutz gegen elektrostatische Entladung) • 1 x RJ-45-LAN-Port mit LED (Aktivität/Verbindung-LED und Geschwindigkeit-LED) • HD-Audioanschlüsse: Line-in / Vorderer Lautsprecher / Mikrofon H610M-HDV: • 1 x D-Sub-Port • 1 x HDMI-Port • 1 x DisplayPort 1.4 H610M-HVS: • 1 x D-Sub-Port...

  • Seite 27: Anschluss

    H610M-HDV H610M-HVS Anschluss • 1 x SPI-TPM-Stiftleiste • 1 x Gehäuseeingriff- und Lautsprecher-Stiftleiste • 1 x CPU-Lüfteranschluss (4-polig) * Der CPU-Lüfteranschluss unterstützt einen CPU-Lüfter mit einer maximalen Lüfterleistung von 1 A (12 W). • 1 x Anschluss Gehäuse/Wasserpumpenlüfter (4-polig) (intelligente Lüftergeschwindigkeitssteuerung) * Der Gehäuse-/Wasserpumpenlüfter unterstützt einen...
  • Seite 28 • Prend en charge les mémoires sans tampon non ECC DDR4 jusqu’à 3200* * Veuillez consulter la liste de prise en charge des mémoires sur le site Web d'ASRock pour de plus amples informations. (http://www.asrock.com/) • Prend en charge les modules mémoire UDIMM ECC (fonctionne en mode non-ECC) • Capacité...
  • Seite 29 H610M-HDV H610M-HVS • Prend en charge le mode D-Sub avec une résolution maximale de 1920x1200 @ 60Hz • Prend en charge HDCP 2.3 avec ports HDMI 2.1 compatibles TMDS et DisplayPort 1.4 H610M-HVS: • Double sortie graphique : Prend en charge les ports D-Sub et HDMI via contrôleurs d’affichage indépendants...
  • Seite 30 Connecteur • 1 x embase SPI TPM • 1 x prise LED d’alimentation et emplacement sur châssis • 1 x connecteur pour ventilateur de CPU (4 broches) * Le connecteur pour ventilateur de CPU prend en charge un ventilateur de CPU d'une puissance maximale de 1 A (12 W). • 1 x connecteur pour ventilateur de châssis /pompe à...
  • Seite 31 • Supporta DDR4 non ECC, memoria senza buffer fino a 3200* * Per maggiori informazioni fare riferimento all'elenco dei supporti di memoria sul sito di ASRock. (http://www.asrock.com/) • Supporta moduli di memoria ECC UDIMM (funziona in modalità non ECC) • Capacità max. della memoria di sistema: 64GB • Supporto di XMP (Extreme Memory Profile) Intel®...
  • Seite 32 • 1 x porta LAN RJ-45 con LED (ACT/LINK LED e SPEED LED) • Connettori audio HD: Ingresso linea / altoparlante frontale / microfono H610M-HDV: • 1 x porta D-Sub • 1 x porta HDMI • 1 x DisplayPort 1.4 H610M-HVS: • 1 x porta D-Sub...
  • Seite 33 H610M-HDV H610M-HVS Connettore • 1 x connettore SPI TPM • 1 x collegamento altoparlante e intrusione telaio • 1 x connettore ventola CPU (4-pin) * Il connettore ventola CPU supporta ventole CPU con potenza massima di 1 A (12 W).
  • Seite 34 • Admite memoria DDR4 no ECC, sin búfer de hasta 3200* * Para obtener más información, consulte la lista de memorias compatibles en el sitio web de ASRock. (http://www.asrock.com/) • Admite módulos de memoria UDIMM ECC (funcionamiento en modo no ECC) • Capacidad máxima de memoria del sistema: 64GB...
  • Seite 35 H610M-HDV H610M-HVS • Admite D-Sub con una resolución máxima de 1920x1200 a 60 Hz • Admite HDCP 2.3 con HDMI 2.1 compatible con TMDS y puertos DisplayPort 1.4 H610M-HVS: • Salida gráfica dual: Compatible con puertos HDMI y D-Sub mediante controladores de pantalla independientes • Compatible con HDMI 2.1 TMDS con una resolución máxima de...
  • Seite 36 Conector • 1 x Conector SPI TPM • 1 x cabezal de intrusión de chasis y de altavoces • 1 x Conector para ventilador de la CPU (4 contactos) * El conector para ventilador de la CPU admite ventilador de la CPU con una potencia de ventilador de 1 A (12 W) máxima.

  • Seite 37: Технические Характеристики

    • 2 x гнезда DDR4 DIMM • Поддержка небуферизованной памяти DDR4 не-ECC до 3200* * Дополнительная информация представлена в Списке совместимой памяти (Memory Support List) на веб-сайте ASRock. (http://www.asrock.com/) • Поддержка модулей памяти ECC UDIMM (работа в режиме, отличном от ЕСС) • Максимальный...
  • Seite 38 • 4 x порта USB 2.0 (с защитой от электростатических разрядов) • 1 x порт ЛВС RJ-45 с индикаторами (Активность/Соединение и Скорость) • Разъемы HD Audio: линейный вход / фронтальные АС / микрофон H610M-HDV: • 1 порт D-Sub • 1 x порт HDMI • 1 порт DisplayPort 1.4 H610M-HVS: • 1 порт...
  • Seite 39 H610M-HDV H610M-HVS Разъемы • 1 x колодка SPI ТРМ • 1 x колодка с разъемами датчика вскрытия корпуса и динамика • 1 x разъем для вентилятора охлаждения ЦП (4-контактный) * Разъем процессорного вентилятора поддерживает вентилятор с потребляемым током не более 1 А (12 Вт).

  • Seite 40: Especificações

    • 2 x Slots DIMM DDR4 • Suporta DDR4 não-ECC, memória sem buffer até 3200* * Por favor, consulte a Lista de Suporte de Memória no site da ASRock para obter mais informação. (http://www.asrock.com/) • Suporta módulos de memória ECC UDIMM (opera em modo não- ECC) • Capacidade máxima da memória do sistema: 64GB...
  • Seite 41 H610M-HDV H610M-HVS • Suporta D-Sub com resolução máxima de até 1920x1200 @ 60Hz • Obsługa HDCP 2.3 przy zgodności z HDMI 2.1 TMDS i porty DisplayPort 1.4 H610M-HVS: • Saída gráfica dupla: Suporta portas HDMI e D-Sub por controladores de vídeo independentes • Suporta HDMI 2.1 TMDS Compatível com resolução máx.
  • Seite 42 Conector • 1 x Suporte SPI TPM • 1 x Intrusão do Chassi e Cabeçote de Autofalante • 1 x Conector da ventoinha da CPU (4 pinos) * O Conector do Ventilador de CPU suporta o ventilador de CPU de alimentação máxima 1A do ventilador (12W).
  • Seite 43 • Technologia pamięci Dual Channel DDR4 • 2 x gniazda DDR4 DIMM • Obsługa niebuforowanej pamięci DDR4 non-ECC, do 3200* * Sprawdź listę obsługiwanej pamięci na stronie internetowej ASRock w celu uzyskania dalszych informacji. (http://www.asrock.com/) • Obsługa modułów pamięci ECC UDIMM (działanie w trybie non- ECC) • Maks.
  • Seite 44 Wyjścia • 1 x port LAN RJ-45 z LED (LED ACT/LINK i LED SPEED) • Gniazda audio HD: Wejście liniowe / Głośnik przedni / Mikrofon H610M-HDV: • 1 x port D-Sub • 1 x port HDMI • 1 x DisplayPort 1.4 H610M-HVS: • 1 x port D-Sub...
  • Seite 45 H610M-HDV H610M-HVS Złącze • 1 x złącze główkowe SPI TPM • 1 x złącze główkowe naruszenia obudowy i głośnika • 1 x złącze wentylatora CPU (4-pinowe) * Złącze wentylatora CPU obsługuje wentylator CPU maksymalnym prądem zasilania wentylatora 1A (12W). • 1 x złącza wentylatora obudowy/pompy wodnej (4-pinowe) (Inteligentne sterowanie prędkością...
  • Seite 46 • DDR4 DIMM 슬롯 2 개 • DDR4 비 ECC, 비버퍼링 메모리 최대 3200 지원 * * 추가 정보를 원하시면 ASRock 웹사이트에 있는 메모리 지원 목록을 참조하십시오 . (http://www.asrock.com/) • ECC UDIMM 메모리 모듈 ( 비 -ECC 모드에서 작동함 ) 지원...
  • Seite 47 H610M-HDV H610M-HVS • D-Sub 지원 ( 최대 해상도 1920x1200 @ 60Hz) • HDMI 2.1 TMDS 호환 HDCP 2.3 및 DisplayPort 1.4 포트 지원 H610M-HVS: • 이중 그래픽 출력 : 독립적 디스플레이 컨트롤러로 HDMI 및 D-Sub 포트 지원 • HDMI 2.1 TMDS 지원 ( 최대 해상도 4K x 2K (4096x2160) @ 60Hz) •...
  • Seite 48 • SPI TPM 헤더 1 개 커넥터 • 섀시 침입 및 스피커 헤더 1 개 • CPU 팬 커넥터 (4 핀 ) 1 개 * CPU 팬 커넥터는 팬 전력이 최대 1A(12W) 인 CPU 팬을 지원합니다 . • 섀시 / 워터 펌프 팬 커넥터 (4 핀 ) 1 개 ( 스마트 팬 속도 제어 ) * 섀시...
  • Seite 49 • デュアルチャンネル DDR4 メモリ機能 メモリ • 2 x DDR4 DIMM スロット • 最大 3200 の DDR4 ノン ECC、アンバッファードメモリに 対応 * * 詳細については、 ASRockウェブサイトのメモリーサポート一覧を 参照してください。 (http://www.asrock.com/) • ECC UDIMM メモリモジュールに対応 （non-ECC モードで動作） • システムメモリの最大容量：64GB • Intel® エクストリームメモリプロファイル (XMP) 2.0 に対応 • 1 x PCIe Gen4x16 スロット * 拡張スロット...
  • Seite 50 • 4 x USB 2.0 ポート（静電気放電 (ESD) 保護に対応） • LED 付き 1 x RJ-45 LAN ポート （ACT/LINK LED と SPEED LED） • HD オーディオジャック ： ラインイン/フロントスピーカー/マイク H610M-HDV: • 1 x D-Sub ポート • 1 x HDMI ポート • 1 x DisplayPort 1.4 H610M-HVS: •...
  • Seite 51 H610M-HDV H610M-HVS • 1 x SPI TPM ヘッダー コネクタ • 1 x シャーシイントルージョンとスピーカーヘッダー • 1 x CPU ファンコネクタ（4 ピン） * CPU ファンコネクタは最大 1A (12W) の電力の CPU ファンに対応 します。 • 1 x シャーシ/ウォーターポンプファンコネクタ （4 ピン） （スマートフ ァン速度制御） * シャーシ/ウォーターポンプファンは最大 2A (24W) の出力のウォー...
  • Seite 52 • 只有 GPU 集成的处理器才支持 Intel® UHD Graphics 内置视效 图形 和 VGA 输出。 • Intel® X 图形架构 (Gen 12) H610M-HDV: • 3 个图形输出选项：D-Sub、HDMI 和 DisplayPort 1.4 • 支持兼容 TMDS 的 HDMI 2.1，60Hz 时最大分辨率达 4K x 2K (4096x2160) • 支持 DisplayPort 1.4，DSC（压缩）最大分辨率可达 8K...
  • Seite 53 H610M-HDV H610M-HVS • 支持 D-Sub，60Hz 时最大分辨率达 1920x1200 • 支持 HDCP 2.3 及兼容 TMDS 的 HDMI 2.1 以及 DisplayPort 1.4 端口 H610M-HVS: • 双图形输出：通过独立显示控制器支持 HDMI 和 D-Sub 端口 • 支持兼容 TMDS 的 HDMI 2.1，60Hz 时最大分辨率达 4K x 2K (4096x2160) • 支持 D-Sub，60Hz 时最大分辨率达 1920x1200 •...
  • Seite 54 • 1 x SPI TPM 接脚 接口 • 1 x 机箱侵入和扬声器接脚 • 1 x CPU 风扇接口（4 针） * CPU 风扇接口支持最高 1A (12W) 功率的 CPU 风扇。 • 1 x 机箱 / 水泵风扇接口（4 针）（智能风扇速度控制） * 机箱 / 水泵风扇支持最高 2A (24W) 功率的水冷风扇。 * CHA_FAN1/WP 可以自动检测 3 针脚或 4 针脚风扇是否在使用。 •...
  • Seite 55 H610M-HDV H610M-HVS 电子信息产品污染控制标示 依据中国发布的「电子信息产品污染控制管理办法」及 SJ/T 11364-2006「电子信息产 品污染控制标示要求」，电子信息产品应进行标示，藉以向消费者揭露产品中含有的 有毒有害物质或元素不致发生外泄或突变从而对环境造成污染或对人身、财产造成严 重损害的期限。依上述规定，您可于本产品之印刷电路板上看见图一之标示。图一中 之数字为产品之环保使用期限。由此可知此主板之环保使用期限为 10 年。 图一 有毒有害物质或元素的名称及含量说明 若您欲了解此产品的有毒有害物质或元素的名称及含量说明，请参照以下表格及说明。 有害物质或元素 部件名称 铅 (Pb) 镉 (Cd) 汞 (Hg) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 印刷电路板 及电子组件 外部信号连 接头及线材 O: 表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 标准规定的 限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T 11363-2006 标准...
  • Seite 56 • 僅限整合 GPU 的處理器才可支援 Intel® UHD Graphics Built-in 顯示卡 Visuals 及 VGA 輸出。 • Intel® X 顯示卡架構（第 12 代） H610M-HDV: • 三個圖形輸出選項：D-Sub、HDMI 及 DisplayPort 1.4 • 最高支援 4K x 2K (4096x2160) @ 60Hz 解析度的 HDMI 2.1 TMDS 相容性 • 支援 DisplayPort 1.4，DSC（壓縮）最大解析度高達 8K...
  • Seite 57 H610M-HDV H610M-HVS • 最高支援 1920x1200 @ 60Hz 解析度的 D-Sub • 支援 HDCP 2.3， 具 HDMI 2.1 TMDS 相容性和 DisplayPort 1.4 連接埠 H610M-HVS: • 雙圖形輸出：透過獨立顯示控制器支援 HDMI 及 D-Sub 連接 埠 • 最高支援 4K x 2K (4096x2160) @ 60Hz 解析度的 HDMI 2.1 TMDS 相容性...
  • Seite 58 • 1 x SPI TPM 排針 接頭 • 1 x 機殼防護及喇叭排針 • 1 x CPU 風扇接頭 (4-pin) * CPU 風扇接頭支援最高 1A (12W) 風扇功率的 CPU 風扇。 • 1 x 機殼／水冷幫浦風扇接頭 (4-pin) （智慧型風扇速度控制） * 機殼／水冷幫浦風扇接頭支援最高 2A (24W) 風扇功率的水冷 風扇。 * 如果 3-pin 或 4-pin 風扇使用中， 可自動偵測 CHA_FAN1/WP。 •...
  • Seite 59 • Teknologi Memori DDR4 Dua Saluran • 2 x Slot DIMM DDR4 • Mendukung memori DDR4 non-ECC, tanpa buffer hingga 3200* * Lihat Daftar Dukungan Memori pada situs web ASRock untuk informasi selengkapnya. (http://www.asrock.com/) • Mendukung modul memori ECC UDIMM (berjalan dalam mode non-ECC) • Kapasitas maksimum memori sistem: 64GB...
  • Seite 60 • 4 x Port USB 2.0 (Mendukung Perlindungan dari ESD) • 1 x Port LAN RJ-45 dengan LED (LED ACT/LINK dan LED SPEED) • Soket Audio HD: Saluran Masuk/Speaker Depan/Mikrofon H610M-HDV: • 1 x Port D-Sub • 1 x Port HDMI • 1 x DisplayPort 1.4 H610M-HVS: • 1 x Port D-Sub...
  • Seite 61 H610M-HDV H610M-HVS Konektor • 1 x Header SPI TPM • 1 x Intrusi Sasis dan Header Speaker • 1 x Konektor Kipas CPU (4-pin) * Konektor Kipas CPU mendukung kipas CPU dengan daya kipas maksimum 1A (12W). • 1 x Konektor Kipas Chassis/Pompa Air (4-pin) (Kontrol Kecepatan...

  • Seite 62: Contact Information

    Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at http://www.asrock.com/support/tsd.asp...

  • Seite 63: Declaration Of Conformity

    Address: Phone/Fax No: +1-909-590-8308/+1-909-590-1026 hereby declares that the product Product Name : Motherboard H610M-HDV / H610M-HVS Model Number : Conforms to the following speci cations: FCC Part 15, Subpart B, Unintentional Radiators Supplementary Information: is device complies with part 15 of the FCC Rules. Operation is subject to the...

  • Seite 64: Eu Declaration Of Conformity

    EU Declaration of Conformity For the following equipment: Motherboard (Product Name) H610M-HDV / H610M-HVS / ASRock (Model Designation / Trade Name) ASRock Incorporation (Manufacturer Name) 2F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District, Taipei City 112, Taiwan (R.O.C.) (Manufacturer Address)

Diese Anleitung auch für:

H610m-hvs
