5.3 Danfoss RAVL Valve
5.3.1 Check the is active.
5.3.2 The valve bodied have elongated notches around
their circumference, which ensure that the adapter is
properly seated when it snaps on: snap on the adapter
completely,so that the pins inside the adapter are lined up
with the notches on the valve.
5.3.3 Install the adapter,Plane A is aligned with Plane B.
5.3.4 Install the round tube into the device.
5.3.5 Install the device.
