33. Before turning on the heater, always make sure that it is
dry.

TECHNICAL DATA

Connection voltage
Power
Power setting options
Insulation class
Remote control
Height
Diameter of the cap
Diameter of the foot
Weight
INSTALLATION
General
• Remove the packaging materials and keep these out of the reach of children.
Check whether all the parts are present. Make sure that no packaging materials
around the 'head' of the spotlight (lamp, cap and switches) have been left behind.
Ensure a tidy workplace and keep flammable materials away.
• Check the appliance, the electric cable and the plug for damage. If you notice any
damage, do not connect the appliance to the electricity grid!
• Do not connect the terrace heater to electricity before you have finished
assembling it!
• You will need a number of suitable wrenches to assemble the terrace heater.
Follow the instructions below step by step. If you have any doubts, consult your
dealer.
220-240V~ 50-60Hz
2000 Watt
800-1200-2000 Watt
IPX4
Yes
230 cm
Ø 42 cm
Ø 47 cm
14,1 kg
List of parts
1
2
1. Heating cap
2. Upper tube
3. Middle tube
4. Lower tube
5. Power cord with plug
6. Foot
5
3
4
7. Foot anchor
8. Decorative ring
8
6
7
Assembling
Make sure that two people work together to assemble the terrace heater.
Step 1
- Pull the power cord via the bottom side through
- Screw the lower tube tightly to the foot using the
- Place the decorative ring on the tube.
50 | 51
the foot and the lower tube (the plug remains at
the bottom side).
four M6x35 screws. Make sure that the four nuts
are at the underside of the foot. (see imge 1)
GB
