ENGLISH

1. PARTS AND COMPONENTS

Fig. 1.
1. Mounting bracket
2. Hanging ball
3. Downrod
4. Stop pin clip
5. Clevis pin
6. Canopy
7. Canopy screws
8. Connections cover
9. Motor
10. Blade
11. Washers
12. Blade screw
13. Holder
14. Fixing screws
15. Screws
16. LED lamp
17. Actuator
18. Remote control

2. BEFORE USE

Take all the product components out of the box and make sure all of them are included and in
good conditions.
If any sign of visible damage is observed, contact immediately with our official Technical
Support Service.
To prevent personal injury and damage, make sure that the location where the device is
going to be installed allows a 2,3-metre clearance from the blades to the floor and a 76-cm
clearance from the blades to any wall or object.
Fig. 2
Make sure that the building structure can hold the full weight of the fan.
This fan can be installed on a normal or vaulted ceiling with a down rod. The hanging length
can be extended by using a longer down rod.
Fig. 3
40 ENERGYSILENCE 5200 / 5250 WHITE DESIGN
ENERGYSILENCE 5200 / 5250 BLACK DESIGN

3. PRODUCT ASSEMBLY

Installation of the mounting bracket, canopy and hanging ball
Make 8 8-mm holes in the concrete ceiling and secure the mounting bracket. It is suggested
to fix it with the 2 long screws supplied within the package.
Wooden ceiling. Fig. 4
Concrete ceiling. Fig. 5
Introduce the fan into the mounting bracket and align the hanging ball slot with the mounting
bracket.
Fig. 6
To extend the hanging length of the fan, remove the hanging ball from the downrod and use
the longer downrod included.
To remove the hanging ball, loosen the set screw on the hanging ball and remove the pun and
clip. Lower the hanging ball and remove the stop pin. Slide the hanging ball off the original
downrod A and slide it down the longer downrod B. The top of the downrod should be noted
as having a set screw hole; use this hole when setting the set screw.
Insert the stop pin into the top of the extended downrod and raise the hanging ball. Make
sure the stop pin aligns with the slots on the inside of the hanging ball and tighten the set
screw securely.
Tip: To prepare for threading the electrical wire through the downrod, apply a small piece of
electrical tape to the ends of the electrical wired, this will keep the wired together.
Loosen the screws and nuts on the top part of the motor housing. Remove the pin and clip
from the down rod if you have not done it previously. Slide the down rod through the canopy.
Pass the cables through the downrod and pull the extra wire slack from the upper end of the
downrod.
Place the downrod into the motor housing and re-insert the pin and clip that were previously
removed. Tighten the screws and nuts securely. Lower the canopy to the motor housing.
Fig. 7
Canopy assembly
Fig. 8
Raise the canopy to the mounting bracket, aligning the loosened screws in the mounting
bracket with the holes in the canopy. Turn the canopy to lock it. Re-insert the screws and
secure them all with a screwdriver.
