STEP 3 – PASO 3 – ÉTAPE 3 – FASE 3 – STEP 3 – STAP 3
Put the Handlebar Post (pt.19) slip into the handlebar post tube on the main frame. You will have to slacken the
Knob (pt.11) and pull the knob back. Then select the desired height. Release the knob and retighten the knob.
The Handlebar (pt.25) fixed on the Handlebar Post (pt.19) with the Knob (pt.12) and the Flat Washer (pt.13).
The Bluetooth Holder (pt.81) fixed on the handlebar as shown.The Plug (A1) of the Sensing Line inserted into the
sensor input hole on the Bluetooth Holder.
Gap
A2
A1
Convex point
STEP 4 – PASO 4 – ÉTAPE 4 – FASE 4 – STEP 4 – STAP 4
The Pedals (pt.8L & pt.8R) are marked "L" and "R" - Left and Right. Connect them to their appropriate crank
arms. The right crank arm is on the right- hand side of the cycle as you sit on it. Note that the Right pedal should
be threaded on clockwise and the Left pedal anticlockwise.
