Diese Anleitung stellt alle benötigten Informationen bereit Eine ausführliche Betriebsanleitung und weitere Informatio- für den Einbau und Anschluss des dezentralen E/A-Moduls nen zu diesem Produkt finden Sie unter www.balluff.com BNI IOW-302… mit digitalen Ein- und Ausgängen sowie auf der Produktseite.
Seite 3
BNI IOW-302-W01-K080 Netzwerkschnittstelle Aufbau und Funktion Bedien- und Anzeigeelemente Port-LED 1 Port-LED 2 LED US Signal Bedeutung Rot blinkend, -Spannung Fehler, Spannung kleiner Port 7 Port 8 3 Hz als ca.: 14V Rot wech- Spannung außerhalb des Nennbereichs, Port 5 Port 6 selnd mit LED die wireless IO-Link Kommunikation läuft...
Seite 4
BNI IOW-302-W01-K080 Netzwerkschnittstelle Elektrischer Anschluss Elektrischer Anschluss Spannungsversorgung E/A-Port ACHTUNG Ungewollte Spannungseinbrüche Nicht getrennte Stromkreise der Spannungsversorgun- gen für Sensor und Aktor können beim Schalten von Draufsicht auf M12-Buchse, A-codiert Aktoren zu ungewollten Spannungseinbrüchen der Sensorversorgung führen. Signal ► Spannungsversorgungen für Sensorik und Aktorik +24 V (Sensorversorgung) getrennt absichern.
This guide provides important information for the A comprehensive user’s guide and additional information installation and connection of the BNI IOW-302... about this product can be found at www.balluff.com on distributed I/O module with digital inputs and outputs and the product page.
Seite 6
BNI IOW-302-W01-K080 Network interface Design and function Operating and display elements Port-LED 1 Port-LED 2 LED US Signal Meaning Red flashing, voltage error, voltage lower than Port 7 Port 8 3 Hz approx.: 14V Red, Voltage outside the nominal range, Port 5...
Seite 7
BNI IOW-302-W01-K080 Network interface Electrical connection Electrical connection Power supply E/A-Port NOTICE Unwanted voltage dips Non-separated electric circuits of the power supplies for sensor and actuator can lead to unwanted voltage dips Top view of M12 socket, A-coded of the sensor supply when switching actuators.
Seite 8
