Included Content
ENGINE
• Muffler (EVOG15601)
• Muffler Screws & Gasket (EVO9191A)
• Spark Plug (EVOG10350)
• Evolution/Spektrum
Telemetry RPM
™
adapter cable (EVOA107)
• Medium Gas-FKM Fuel Tubing (EVOA104)
• In-Line Fuel Filter (EVOA105)
• In-tank Felt Filter/Clunk (EVOA106)
Fuel Nipple
High-Speed
Needle
Muffler
Installing the Engine
1. Secure the engine mount on the airplane
firewall. Tighten the engine mount screws
in the firewall.
2. Install the engine on the engine mount
according to the airplane manufacturer's
instructions.
WARNING: Tighten all engine
mounting screws before each flight. If
you do not tighten the engine
mounting screws, the screws may
vibrate loose and cause the engine to
separate from the fuselage.
OPTIONAL ITEMS
• Tachometer (HAN156)
• Propeller 13 x 6 (EVO13060) for break-in;
14 x 6 (EVO14060) for normal flight
• Optical Electronic Ignition Kill Switch
(EVOA100)
• Evolution Synthetic 2-Cycle Oil, (EVOX1001Q)
• Ultra Fuel Pump (HAN155)
Spark Plug
Spark Plug
Muffler Nipple
Muffler
Low-Speed
Needle
Throttle
Arm
EN
5
