elgris SMART METER WiFi Bedienungsanleitung Seite 15

Address Size Name
40102 1 PF
40103 1 PFphA
40104 1 PFphB
40105 1 PFphC
40106 1 PF_SF
40107 2 TotWhExp
40109 2 TotWhExpPhA
40111 2 TotWhExpPhB
40113 2 TotWhExpPhC
40115 2 TotWhImp
40117 2 TotWhImpPhA
40119 2 TotWhImpPhB
40121 2 TotWhImpPhC
40123 1 TotWhSF
40125 2 TotVARhExp
40127 2 TotVARhExpPhA
40129 2 TotVARhExpPhB
40131 2 TotVARhExpPhC
40133 2 TotVARhImp
40135 2 TotVARhImpPhA
40137 2 TotVARhImpPhB
40139 2 TotVARhImpPhC
40140 1 TotVARh_SF
40141 1 Evt
Version: 20. Januar 2022 07:57
Label Value Type R/W
PF int16
PF phase A int16
PF phase B int16
PF phase C int16
sunssf
acc32
acc32
acc32
acc32
acc32
acc32
acc32
acc32
sunssf
acc32
acc32
acc32
acc32
acc32
acc32
acc32
acc32
sunssf
Events bitf32
www.elgris.de
Description
R Power factor
R
R
R
R Power factor scale factor
R Total Wh exported
R Total Wh exported phase A
R Total Wh exported phase B
R Total Wh exported phase C
R Total Wh imported
R Total Wh imported phase A
R Total Wh imported phase B
R Total Wh imported phase C
R Real energy scale factor
R Total VAR exported
R Total VAR exported phase A
R Total VAR exported phase B
R Total VAR exported phase C
R Total VAR imported
R Total VAR imported phase A
R Total VAR imported phase B
R Total VAR imported phase C
R Reactive energy scale factor
R Not supported yet
Page 15 of 17
