MC-Fastpack Power-Tool

7) OPERATION

Inserting the cartridge

Refer to the figure {B} on page 2:
CAUTION
Risk of crushing by extending plunger!
1 . Always push the cartridge with different volume ratios with the higher volume
(A-side) upwards into the guides (1) and press downwards until it locks into
place.

Connect the dispenser to the compressed air supply

Risk of damage due to incorrect compressed air supply!
NOTICE
E O bserve the maximum supply pressure of the compressed air supply. Refer to
Chapter "10) Technical data" on page 8.
1 . Connect the compressed air hose onto the compressed air inlet with the quick-
release coupling.

Leveling the cartridge pistons

Refer to figures {D} and {E} on page 2:
1 . Remove the retaining nut (11) and nose plug by turning it by 120° counter-
clockwise.
2 . Set the pressure regulation valve (8) to the minimum discharge quantity.
3 . Press the trigger (7) until both components are evenly pressed out of the
cartridge.

Fitting the mixer

Refer to figure {F} on page 2:
1 . Fit the mixer (a) and secure in place by using the retaining nut on the cartridge
outlet (b).
12
MC-Bauchemie Müller GmbH & Co. KG
01-2021
