Selecting the
high-pressure nozzles
You need to use the matching high-pres-
sure nozzles to ensure that your high-pres-
sure cleaner works properly.
Note: Nominal pressure (p): See Operating
Instructions or type plate of your high-pres-
sure cleaner.
Grey high-pressure nozzles (already
installed)
Suitable for high-pressure cleaners with
–
nominal pressure (p)* up to max.
12 MPa (120 bar).
You can use the premounted grey high-
pressure nozzles.
Yellow high-pressure nozzles
Suitable for high-pressure cleaners with
–
nominal pressure (p)* up to max.
12 MPa (120 bar).
You need to replace the grey high-pressure
nozzles that have been installed by the yel-
low high-pressure nozzles to ensure that
you can work in a trouble-free manner with
your high-pressure cleaner.
Changing the high-pressure nozzles
1 Remove the clip.
2 Pull out the grey high-pressure nozzle.
3 Insert yellow high-pressure nozzle.
4 Re-insert the clip.
10 English

Cleaning floor surfaces

Fasten the surface cleaner to the high-
pressure gun using the extension pipes.
Attaching the extension tubes
1 Press one extension tube into the bayo-
net catch of the high-pressure gun.
2 Turn it by 90° until it locks into place.
3 Tighten the locking joint.
Repeat the above steps for the other
two bayonet-type connections.
Please observe:
Outdoor surfaces should be swept be-
–
fore the surface cleaner is used to avoid
damaging the high-pressure nozzles.
The surface cleaner is not suitable for
–
sraping or scrubbing!
Adjusting the cleaning performance
Robust surfaces (for e.g. tiles, concrete,
stone)
Set the height adjustment of the noz-
zles to "+".
Sensitive surfaces (for e.g. wood)
Set the height adjustment of the noz-
zles to "–".
