V. FOLDING
As gure 5.1, step1- fold the canopy; step 2 - adjust the backrest forwards to be; step 3-push the leg-rest as arrow direction till the stroller become ; step 4- one
hand holds the push bar adjust button, at the same time another hand holds the safety lock button and then follow as 5 arrow direction to push hard to the end;
step 6- move the push bar downwards till the stroller as gure please always make sure the folding lock is locked.
Seat backwards folding steps:
As gure 5.2 , adjust backrest backward to the end. Same operation as seat forward state, fold till the folding lock is locked.
VI. SWIVEL LOCK
Front wheels swivel: As gure 6.1,keep the button up.
As gure 6.2,Close swivel function: push the button down.
Applying the brake: As gure 6.3, step down the pedal"1"to engaging the brakes. Step down the pedal "2" to release the brakes.
Note :Please engage the brake when the stroller isn't moving.
VII. BACKREST ADJUSTMENT FUNCTION
As gure 7.1,7.2 push the backrest upward and adjust directly. Switch to lying sate needs to pull then adjust backrest.
VIII. LEG REST ADJUSTMENT
As gure 8.1 with two hands press toward arrow direction at same time, adjust upwards or downwards. 3 positions adjustment.
IX. CANOPY ADJUSTMENT
As gure 8.2 outward and inward to adjust the canopy, one hidden canopy, unzip, otward to open the hidden canopy, push inward to close the hidden canopy.
X. BUMPER BAR
As gure 10.1,10.2, press inside button of bumper bar then pull out. Assembling bumper bar: put it into the socker till "click"sound.
XI. ASSEMBLE THE CARRYCOT
Unfolding the carrycot, remove the bedding and the mattress, and then pull the metal tensioners in the direction of the arrows, gure 11.1,11.2. You should hear
a "click"sounds locking the tensioner in the holder.
Put the carrycot onto the stroller in a parent-facing position until you heara "click"sound. Figure 11.3. Press the button on the both sides of the carrycot upwards
to remove. Figure 11.4,11.5.
WARNING!Always check the carrycot is secure once locked in place by gently pulling up on either side.
ADJUST THE CARRYCOT CANOPY. Hold the canopy tube push as the arrow direction to front and rear.
WARNING! Please remain the canopy tube at 90 degree position when lifting the carrycot by canopy tube. Improper handling may harm the baby.
XII. INSTALL AND TAKE OFF THE ADAPTORS FOR CAR SEAT
Insert the adapters into the car seat in the right direction as gure 12.1 indicated, until you hear a "click" sound.
Press the button at the side of the car seat and at the same time pull out the car seat adaptors with slight strength as gure 12.3, you can take o the car seat
adaptors.
Put the the adaptors right above the stroller frame letting the adaptor alignment with the socket on the stroller, then push the adapters down with slight
strength until you hear a "click" sound, meaning the adapters are properly installed in the stroller frame. Then put car seat , letting adaptors alignment with the
car seat slot, push the car seat down with slight strength until you hear a "click" sound,meaning the car seat are properly installed in the adapters.(Figure 12.4
12.5)
NOTE: Only use the car seat on the stroller frame in a parent-facing position.
WARNING:Always check the car seat is secure once locked in place by gently pulling up on either side.
Push up the buttons at the middle of the adaptors at the same time pull up the car sear adaptors, you can take o the car seat from the stroller.(Figure 12.6)
XIII. CARE AND CLEANING
Fabric parts:
The fabrics of the product must be cleaned with warm water and mild soap.
Plastic and metal parts:
1. The plastic and metal parts must be cleaned with a damp soft cloth and dried with dry soft cloth.
2. Do not let the product exposed to the harmful effect of external factors - direct sunlight, rain, snow or wind. This may lead to damage of the metal and plastic parts and
fading of the fabrics.
3. When you are not using the product, store it at a dry and well ventilated place, not in dusty, humid premises with very high or very low room temperatures.
Frame: From time to time check all plastic parts that are hanged on the frame. Tighten all screw and bolts if necessary.
