Konsta Lindos Bedienungsanleitung

Lindos 340 x 280cm
Important information
Please check the construction set for completeness using the position list in good time before starting con-
struction or commissioning your construction team. If individual parts are defective or missing, we will deliver
these as quickly as possible. However, we cannot refund the costs for any resulting construction delays to a
construction company.
Please understand that we cannot assume any guarantee for the following defects:
- incorrect storage before assembly
- incorrect anchoring with the ground or inadequate foundation (foundation according to statics)
- damage due to erection errors, e. g. the house is not level or not right-angled
- damage through a higher level of snow burden than statically envisaged. Recommendation: lad relief of
the roof by removing the snow layer
- storm damage (insurance cases) or violent destruction
- damage through any alteration to the design by the client
- natural formation of cracks, branch holes, twisting, decolouration or similar modification (natural
process; has no influence on the statics)
Storage information until construction :
- store pallet on a level and dry surface.
- Protect from exposure to sunlight and the influences of weather ; wood can warp drastically in a loose
condition!
Maintenance tips:
Please observe the attached information sheet "Care instructions/Colour treatment".
General tips and refers to:
-
1 The packaging foil can be used to keep moisture out of the house. It is laid according to the ground area of the
house under the main bearing.
-
As the house is exposed constantly to the weather, it is necessary to lay a further welding line. You have to make
2
it for your own.
-
3
A possibly desired installation of a rain gutter must be done by the building contractor; for this the roofing boards
must be cut to the right length.
-
Foundation according to the structural calculations (not included in the scope of delivery): concrete C25/30,
1
each 2 Ø 12 top and bottom, brace mat R188A (alternatively brace Ø 6/20cm). Anchoring of the floor beams
(in the building) on the strip foundation using bolts M12, e < 60cm. The base bearings in the storeroom of the
house must be entirely flush.
-
2
During the assembly of the planks it is essential to make sure that the planks are fixed with approx. 1mm
distance and the top planks have the same height all around.
Due to storage, the measurements of the planks may change over time and change the heigth of the wallplanks.
Please remember this during the installation of the
3
-
If the door cannot be closed properly, this can be adjusted by turning the hinges.
-
The roofing boards are laid out up to the inner edge of the outer facing. The final roofing board must be adjusted
4
in width. The roofing boards must be cut out as necessary in the area near the fastening wood H16/58-00 (34cm).
-
5
It is planned to have the roofing paper go up the sides over the existing gap as high as the facing, and to attach it
there on the facing. The building contractor can also lay strips over the gap, or the roofing paper can be laid right
up to the upper edge of the facing; this will then be covered by the aluminium strip A100-220.
Manufactured for Hornbach Baumarkt AG, D-76878 Bornheim.Technical modifications reserved. All dimensions are approximate dimensions. Date 10/18
761548 (unbehandelt)
planks, otherwise it may result in different wall heights.
