TFA WIND BEE Bedienungsanleitung Seite 6

TFA_No. 42.6003 Anleitung_11_21
WIND BEE – Anemometer
Caution!
Risk of injury:
• Keep this device and the battery out of reach of children.
• Small parts can be swallowed by children (under three
years old).
• Batteries contain harmful acids and may be hazardous if
swallowed. If a battery is swallowed, this can lead to seri-
ous internal burns and death within two hours. If you sus-
pect a battery could have been swallowed or otherwise
caught in the body, seek medical help immediately.
• Batteries must not be thrown into a fire, short-circuited,
taken apart or recharged. Risk of explosion!
• Low batteries should be changed as soon as possible to
prevent damage caused by leaking.
• Avoid contact with skin, eyes and mucous membranes when
handling leaking batteries. In case of contact, immediately
rinse the affected areas with water and consult a doctor.
Important information on product safety!
• Do not expose the device to extreme temperatures, vibra-
tions or shocks.
• Protect it from moisture, sand, dirt and dust.
5. Elements
Buttons
ON/OFF button (front)
MAX/MIN button (laterally)
6. Operation
6.1 Getting started
• Open the screw of the battery compartment and insert the
battery 9 V. Ensure that the battery polarity is correct.
10
22.11.2021
Housing (back)
Tripod screw
Battery compartment
(screwed)
11:55 Uhr Seite 6
WIND BEE – Anemometer
• Please pay attention to the connection wires.
• Close the battery compartment again.
• All LCD segments will be displayed for about a few se-
conds.
• The battery symbol, the actual measured temperature, the
measuring unit (default: m/s) and 000:0 appear on the
display.
• The unit is ready for use.
• The device will turn off automatically after 15 minutes, if
no button is pressed.
• Press the ON/OFF button for at least 3 seconds to turn off
the instrument immediately.
6.2 Measuring of the wind speed
• Press the ON/OFF button.
• All LCD segments will be displayed for about a few se-
conds.
• The battery symbol, the actual measured temperature, the
measuring unit (default: m/s) and 000:0 appear on the
display.
• Press and hold the MAX/MIN button to change between
m/s, km/h, Knots, Mph or ft/min as measuring unit.
• Hold the device in the wind.
• The wind speed is displayed in the selected measuring
unit.
6.3 Reading of the maximum and minimum values
• Press the MAX/MIN button to enter the maximum and
minimum mode.
• MAX appears on the display.
• The highest wind speed and the temperature since the last
activating of the device are displayed.
• Press the button again.
• MIN appears on the display.
• The lowest wind speed and the temperature since the last
activating of the device are displayed.
11
