All manuals and user guides at all-guides.com L’appareil que vous venez d’acquérir a été soumis à de nombreux tests et contrôles afin d’en assurer la qualité. Nous vous remercions de ce choix et de votre confiance. Nous espérons qu’il vous apportera une entière satisfaction.
Seite 4
All manuals and user guides at all-guides.com Puissance Hauteur Largeur Epaisseur Cote (A) Cote (B) Cote (C) (H) (mm) (L) (mm) (mm) 600 +1000* 1205 1108 750 +1000* 1530 1433 900 +1000* 1855 1758 * : Puissance d’appoint ventilée. Nota: chevilles livrées avec l’appareil sont de type standard.
Seite 5
All manuals and user guides at all-guides.com 5) Programmation Par fil pilote: L’appareil peut être commandé à distance si son fil pilote est raccordé à un appareil équipé d’un program- mateur, à une centrale de programmation ou à un gestionnaire d’énergie. Tableau des 6 ordres que l’appareil peut recevoir sur son fil pilote (à...
All manuals and user guides at all-guides.com 3) Mode Hors Gel C’est le mode qui permet de maintenir la température à environ 7°C dans la pièce lors d’une absence pro- longée de la maison. a) Laissez l’interrupteur sur la position Marche. b) Réglez la molette 4) Mode Turbo C’est le mode qui permet de mettre l’appareil en Marche Forcée pour augmenter rapidement la tempéra-...
All manuals and user guides at all-guides.com ISE EN GARDE - Les enfants ne doivent pas escalader l’appareil. - Toutes interventions sur les parties électriques doivent être effectuées par un professionnel qualifié. - Veillez à ne pas introduire d’objets ou du papier dans l’appareil. - A la première mise en chauffe, une légère odeur peut apparaître correspondant à...
Seite 8
All manuals and user guides at all-guides.com F i l t r e A n t i - P o u s s i è r e Voyant rouge (pour modèle équipé d’un ventilateur) Le ventilateur est équipé d’un filtre anti-poussière qui, lorsqu’il est saturé, peut provoquer son arrêt (voyant rouge allumé...
All manuals and user guides at all-guides.com The device you have just purchased was submitted to many tests and checks ensuring its quality. We thank you for your choice and trust.We hope you will be fully satisfied. A few recommendations: Read the instructions before installing the device.
All manuals and user guides at all-guides.com Overall Widthr Thickness Measurement Measurement Measurement Power (W) (H) (mm) (L) (mm) (mm) 600 +1000 1205 1108 750 +1000 1530 1433 900 +1000 1855 1758 Note: The pins supplied with the device are of the standard type.
Seite 11
All manuals and user guides at all-guides.com 5) Programming With a pilot wire: The appliance can be controlled remotely if its pilot wire is connected to an appliance fitted with a pro- grammer, to a central programming unit or to an energy control system. Chart indicating the orders the device can receive over its pilot wire (to be measured between the pilot wire and the neutral).
All manuals and user guides at all-guides.com 3) Standby (Hors Gel) Mode It is the mode enabling to maintain a temperature of approximately 7°C in the room in case of prolonged absence from the house. a) Leave switch on the Marche position. b) Set the knob 4) Turbo mode It is the mode enabling to set the device into Forced Operation, ensuring prompt temperature increase...
All manuals and user guides at all-guides.com ARNING - Prevent children from climbing on the device. - Any intervention on the electrical parts must be performed by skilled staff. - Do not insert objects or paper in the device. - Upon first warming, a slight smell may appear, due to the evacuation of compounds used during the device’s manufacturing.
Seite 14
All manuals and user guides at all-guides.com A n t i d u s t f i l t e r Red indicator ( m o d e l f i t t e d w i t h a f a n ) The fan is fitted with an antidust filter which, when clogged, can result in its stoppage (red indicator lit on the device).
Seite 15
........... . * This information can be found on the information plate situated on the left-hand side of the appliance. FOR SALES IN AUSTRALIA ATLANTIC AUSTRALASIA PTY LTD Free Call: 1800 677 857 4/13-25 Church Street...
All manuals and user guides at all-guides.com Das Gerät, dass Sie gerade gekauft haben, wurde auf einwandfreie Qualität getestet und kontrolliert.Wir danken Ihnen für diese Wahl und Ihr Vertrauen und hoffen, dass es Ihren Erwartungen entspricht. Ein paar Tips: Lesen Sie die Bedienungsanleitung, bevor Sie das Gerät installieren. Schalten Sie vor jeder Arbeit am Gerät den Strom ab und überprüfen Sie die Spannung der Stromquelle.
Seite 17
All manuals and user guides at all-guides.com Maß (B) Maß (C) Leistungen Bauhöhe über Breite Maß (A) Stärke (mm) Befestigungspratzen (mm) Befestigungspratzen (mm) alles (H) (mm) (L) (mm) Befestigungspratzen (mm) 600 +1000 1205 1108 750 +1000 1530 1433 900 +1000 1855 1758 Hinweis: Die mitgelieferten Dübel...
Seite 18
All manuals and user guides at all-guides.com 4) Programmierung Per Pilotleiter: Das Gerät kann mit einer Fernbedienung gesteuert werden, wenn sein Pilotleiter an ein Gerät angeschlos- sen ist, das mit einem Programmierer versehen wurde, an eine Programmierzentrale oder an ein Energiemanagementsystem.
All manuals and user guides at all-guides.com 3) Frostschutz-Betrieb Diese Einstellung sorgt dafür, dass bei längerer Abwesenheit der Raum auf einer Temperatur von etwa 7°C bleibt. a) Den Schalter in Stellung Ein lassen. b) Den Rändelknopf stellen. 4) Turbo-Betrieb Diese Einstellung erzwingt eine schnelle Temperaturerhöhung des Raums innerhalb der definierten Dauer (höchste Stufe für die herkömmlichen Modelle und Einschalten des Ventilators für die Modelle mit Gebläse).
All manuals and user guides at all-guides.com ICHERHEITSHINWEISE - Vermeiden Sie, dass Kinder auf das Gerät steigen. - Alle Arbeiten an den Elektroteilen dürfen nur von einer Elektrofachkraft ausgeführt werden. - Darauf achten, dass keine Objekte oder Papier in das Gerät gelangen. - Bei der ersten Beheizung kann ein leichter Geruch entstehen, welcher auf die eventuelle Ableitung hers- tellungsbedingter Spuren zurückzuführen ist.
Seite 21
All manuals and user guides at all-guides.com S t a u b s c h u t z - F i l t e r Rote Lampe (bei Modellen mit Ventilator) Der Ventilator ist mit einem Staubschutzfilter aus- gerüstet, welches bei zu starker Verschmutzung den Stillstand des Ventilators bewirken kann (die rote Anzeigelampe unter dem Gerät leuchtet).
- Die garantiedauer betrâgt zwei Jahre ab dem Installations- oder Kaufdatum. Falls kein Beleg vorgezeigt werden kann, gilt die Garantie für 30 Monate ab dem Herstellerdatum. - ATLANTIC garantiert den Ersatz oder die Lieferung der als fehlerhaft anerkannten Teile, jegliche Schadenshaftpflicht ist ausgesclossen.
All manuals and user guides at all-guides.com Het apparaat dat u zojuist heeft gekocht is veelvuldig getest en gecontroleerd voor een optimale kwali- teit.Wij danken u voor uw keuze en uw vertrouwen.Wij hopen dat u veel plezier zult beleven aan het apparaat.
All manuals and user guides at all-guides.com Maat (B) bevestigingshaken Maat (B) bevestigingshaken Vermogen Buitenhoogte Breedte Dikte Maat (A) bevestigingshaken (mm) (mm) (H) (mm) (L) (mm) (mm) (mm) 600 + 1000 1205 1108 750 + 1000 1530 1433 900 + 1000 1855 1758 Opmerking:De bij het apparaat...
Seite 25
All manuals and user guides at all-guides.com 5) Programmering Het apparaat kan op afstand worden aangestuurd als de stuurdraad is aangesloten op een apparaat met scheduler, een programma-eenheid of een energiebeheerder. Tabel van de commando's die het apparaat kan ontvangen via de stuurdraad (te meten tussen de stuurdraad en de neutrale geleider).
All manuals and user guides at all-guides.com 3) Vorstvrij functie Met deze functie handhaaft u een temperatuur van ongeveer 7°C in het vertrek als u voor langere tijd afwe- zig bent. a) Laat schakelaar op Aan staan. b) Zet schakelaar 4) Turbo functie Met deze functie kunt u het apparaat Geforceerd Activeren om snel de temperatuur van het vertrek te ver- hogen gedurende bepaalde tijd (maximaal vermogen voor de klassieke modellen en aanzetten van de ven-...
All manuals and user guides at all-guides.com AARSCHUWING - Laat de kinderen niet op het apparaat klimmen. - Alle servicebeurten van elektrische onderdelen dienen te worden uitgevoerd door speciaal hiervoor opgeleide technici. - Zorg dat er geen vreemde voorwerpen of papier in het apparaat terechtkomen. - De eerste keer dat u de verwarming gebruikt kan er een lichte geur worden verspreid door de afvoer van eventuele fabricageresten van het apparaat.
Seite 28
All manuals and user guides at all-guides.com S t o f f i l t e r Rood controlelampje (voor modellen met ventilator) De ventilator is uitgerust met een stoffilter die wan- neer hij vol is het apparaat kan uitschakelen (rood controlelampje brandt aan de onderkant van het apparaat).
All manuals and user guides at all-guides.com ARANTIEVOORWAARDEN DOCUMENT DAT DE GEBRUIKER MOET BEWAREN (de verklaring alleen overleggen in geval van een klacht) - De garantie geldt voor een duur van twee jaar met ingang van de datum van installatie of aankoop. - De duur kan de 30 maanden vanaf de fabricagedatum niet overschrijden indien er geen bewijs aan wezig is.
All manuals and user guides at all-guides.com El aparato que acaba de adquirir ha sido sometido a numerosas pruebas y controles con el fin de garan- tizar la calidad. Le agradecemos por su elección y su confianza. Esperamos que le aporte una entera satisfacción.
All manuals and user guides at all-guides.com 4) Programación Por cable piloto: El aparato se puede dirigir a distancia si su cable piloto está conectado a un aparato equipado con un pro- gramador, a una central de programación o a un administrador de energía. Cuadro de las órdenes que el aparato puede recibir en su hilo piloto (a medir entre el hilo piloto y el neutro).
All manuals and user guides at all-guides.com 3) Modo Fuera de Hielo Es el modo que permite mantener la temperatura a aproximadamente 7ºC en la pieza durante una ausen- cia prolongada de la casa. a) Deje el interruptor en la posición Marcha. b) Ajuste la moleta 4) Modo Turbo Es el modo que permite poner el aparato en Marcha Forzada para aumentar rápidamente la temperatura...
All manuals and user guides at all-guides.com DVERTENCIA - Evite que los niños suban al aparato. - Todas las intervenciones en las partes eléctricas deben ser efectuadas por un profesional calificado. - No introduzca objetos o papel en el aparato. - Durante el primer calentamiento, puede aparecer un ligero olor correspondiente a la evacuación de las eventuales trazas vinculadas a la fabricación del aparato.
Seite 35
All manuals and user guides at all-guides.com F i l t r o a n t i p o l v o Indicator rojo (para modelo equipado de un ventilador) El ventilador está equipado de un filtro antipolvo que, cuando se satura, puede provocar su parada (piloto rojo encendido debajo del aparato).
Seite 36
..............*Estos datos se encuentran en la placa situada en el lado derecho del aparato. Sello del instalador Atlantic Ibérica Pol. Industrial Cam í Real Paseo del Ferrocaril, 339 - 2°planta...
All manuals and user guides at all-guides.com O aparelho que acaba de adquirir foi submetido a diversos testes e controlos de maneira a assegurar um alto nível de qualidade. Estamos gratos pela sua escolha e pela sua confiança, e esperamos que este produto lhe traga total satisfação.
Seite 38
All manuals and user guides at all-guides.com Potências Altura total Largura Espessura Cota (A) Cota (B) Cota (C) (H) (mm) (L) (mm) (mm) partes de fixação (mm) partes de fixação (mm) partes de fixação (mm) 600 +1000 1205 1108 750 +1000 1530 1433 900 +1000...
Seite 39
All manuals and user guides at all-guides.com 4) Programação O aparelho pode ser comandado à distância, se o fio piloto de programação estiver ligado a um aparelho equipado com programador, a uma central de programação ou a um sistema de gestão de energia. Quadro dos 6 comandos de programação que o aparelho pode receber através do fio piloto (a medir entre o fio piloto e o neutro).
All manuals and user guides at all-guides.com 3) Modo Anti-Gelo Este modo permite manter a temperatura do cómodo a cerca de 7°C durante ausências prolongadas. a) Deixar o interruptor na posição Liga. b) Ajustar o selector 4) Modo Turbo Este modo permite colocar o aparelho em funcionamento forçado para aumentar rapidamente a tempera- tura do cómodo durante um tempo definido (máximo da potência para os modelos clássicos e colocação em funcionamento do ventilador para os modelos com foles).
All manuals and user guides at all-guides.com RECAUÇÕES DE UTILIZAÇÃO - Evite que as crianças subam no aparelho. - Todas as intervenções na parte eléctrica só devem ser efectuadas por profissionais qualificados. - Não introduza objectos ou papel dentro do aparelho. - No momento da primeira utilização, pode ser que um leve odor se desprenda do aparelho.
Seite 42
All manuals and user guides at all-guides.com F i l t r o a n t i - p ó Sinal luminoso vermelho (para modelos equipados com ventilador) O ventilador está equipado com um filtro anti-pó que, ao atingir a saturação, pode provocar a sua paragem (iluminação de uma luz vermelha sob o aparelho).
Seite 43
..............*Estas informações encontram-se na placa de características situada no lado direito do aparelho. Carimbo do vendedor Atlantic Ibérica Pol. Industrial Cam í Real Paseo del Ferrocaril, 339 - 2°planta...
La durée de garantie est de 2 ans à compter de la date d’installation ou d’achat et ne saurait excéder 30 mois à partir de la date de fabrication en l’absence de justificatif. Atlantic assure l’échange ou la fourniture des pièces reconnues défectueuses à l’exclusion de tous dommages et intérêts.
