INSTALLATION MANUEL INSTALLATION MANUAL
GALEO GALEOR
Illuminated RF Keypad Illuminated RF Keypad
Thank you for buying our products and for the confi dence you placed
in our company.
1] GENERAL INFORMATION
Wireless RF keypad.
Polished heavy duty Zamak
Backlit keys.
Frequency : 433,92 Mhz.
2 channels (buttons «A» and «B»).
Compatible with Erone
Compact.
Surface mount
Mounting with Torx
Partially sealed with epoxy.
22 User codes - 5 digits.
1 Master code - 5 digits.
Audible and visual feedback.
Modulation: AM/ASK.
Encoding: Keeloq
®
Dimensions (L x W x D):
GALEOR = 110 x 75 x 15mm,
Supply: Lithium battery 3,6V - LS14500.
Current consumption:
- 28 mA in transmission,
- 0,8uA in sleep-mode.
2] NOTES & RECOMMENDATIONS
Mounting recommendations
Mount the keypad on a fl at surface to avoid
any vandalism and to insure the best mounting.

3] MOUNTING KIT

(M4x10)
screw)
GALEOR
* Supplied.
All manuals and user guides at all-guides.com
cast alloy.
®
receivers.
®
.
screws
®
hopping code
T20 Torx
®
Torx
®
Spanner
1 1
Environmental tests:
vibrations
WEEE
Environmental test:
Salt spray
IP64
Certifi cation CE
-25°C a +70°C
Certifi cation FCC CFR 47
part 15 compliance
Security advice
For security advice reasons, change
the factory default master code.
When selecting a master code and user code avoid
sequencial codes (example : 3 4 5 6 7).
(M4x30)
Cache vis
mounting
plastique
screws
1 2
77
Plastic
Battery
anchors
2 1
cdvigroup.com
EN
Foam
1
