All manuals and user guides at all-guides.com DEUTSCH ENGLISH GALEOR Funktastatur hintergrundbeleuchtet Illuminated RF keypad ® Reihe: Digicode Range: Digicode ® INSTALLATIONSANLEITUNG INSTALLATION MANUAL Group Products...
All manuals and user guides at all-guides.com INSTALLATIONSANLEITUNG GALEOR Funktastatur hintergrundbeleuchtet Vielen Dank für den Kauf dieses Produkts und Ihr Vertrauen in unserem Unternehmen. 1] PRODUKTVORSTELLUNG Drahtlose Funktastatur. Aluminiumguss. Hintergrundbeleuchtet. Frequenz: 433,92 Mhz. 2 Kanäle (Tasten «A» und «B»). Kompatibel mit ERONE Funkempfängern. Kompakt.
All manuals and user guides at all-guides.com INSTALLATIONSANLEITUNG GALEOR Funktastatur hintergrundbeleuchtet 4] MONTAGE Bohren Sie die Befestigungslöcher (Bohrer Ø 5 mm und Minimaltiefe = 35 mm). Positionieren Sie die beiden Kunststoffdübel in die entsprechenden Löcher. Kleben Sie die Dichtung auf die Rückseite der Sockel zur GALEOR fest (wichtig).
Seite 4
All manuals and user guides at all-guides.com INSTALLATIONSANLEITUNG GALEOR Funktastatur hintergrundbeleuchtet 6] PROGRAMMIERUNG STANDARDWERTE DER GALEOR: PIEPTÖNE: - Kanalfehler - Ohne Codes 1 kurzer Piepton = Unterspannungsetzen - Codefehler (z.B. schon gespeicherter - Summer aktiviert (Batterieeinsatz) Code) - Beleuchtungsverzögerung: 3 Sek 1 langer Piepton: - Funksendung-Sicherheitsverzögerung: - Eintritt ins Menü...
Seite 5
All manuals and user guides at all-guides.com INSTALLATIONSANLEITUNG GALEOR Funktastatur hintergrundbeleuchtet Tippen Sie den ERINNERUNG: MASTERCODE Wenn die Tastatur während 1 Sek beim ersten Kontakt blinkt, zweimal. prüfen Sie die Batterie. Ausgeschaltete Tasten-Hintergrungbeleuchtung, ausser fest eingeschalteter Taste 5 RŰCKSETZUNG Einen Rücksetzung RŰCKSETZUNG Mit oder ohne...
Seite 6
Garantie» für Ihr(e) Produkt (e) zu profi tieren, füllen Sie bitte die in der Produktverpackung einliegende Registrierungs-Karte aus und senden Sie sie per E-mail oder per Post an die Adresse der näheren CDVI Stelle oder registrieren Sie sich unter www.cdvigroup.com oder auf die Rückseite der Installationsanleitung.
All manuals and user guides at all-guides.com INSTALLATION MANUEL INSTALLATION MANUAL GALEO GALEOR Illuminated RF Keypad Illuminated RF Keypad Thank you for buying our products and for the confi dence you placed in our company. 1] GENERAL INFORMATION Wireless RF keypad. Polished heavy duty Zamak cast alloy.
Seite 8
All manuals and user guides at all-guides.com INSTALLATION MANUAL GALEOR Illuminated RF Keypad 4] PROGRAMMING GALEOR FACTORY SETTINGS : AUDIBLE FEEDBACKS : USING RULES AND USER CODES: - No user codes. - All the buttons can be used to 1 beep : Power-up ( battery insertion ) - Buzzer ON 1 long beep : compose the personal access code,...
Seite 9
All manuals and user guides at all-guides.com INSTALLATION MANUAL GALEOR Illuminated RF Keypad REMINDER: Type 2 times the if the keypad blinks during 1 sec. MASTER CODE at the fi rst touch, check the battery. Buttons backlit switch off except button 5 FACTORY RECOVER Master code reset Delete a single...
Seite 10
All manuals and user guides at all-guides.com INSTALLATION MANUAL GALEOR Illuminated RF Keypad 5] MOUNTING Drill the 2 mounting holes (drill bit Ø 5 mm and 35 MM hole depth) and the hole wiring access. Insert the 2 plastic anchors in the holes. Stick the foam to sealed The GALEOR on the back side of the base (Important).
Seite 11
“Limited Lifetime Warranty”, complete the enclosed registration card and return it, either by e-mail or post, to the relevant CDVI address or completion of the on line registration at www.cdvigroup.com. Repair or replacement of the defective product is the exclusive remedy.
Seite 12
All manuals and user guides at all-guides.com Extranet : EXE-CDVI_IM GALEOR CMYK A5 EN-DE 01 Creator of electronic access solutions *G0301FR0420V01* CDVI Group FRANCE (Headquarter/Siège social) Phone: +33 (0)1 48 91 01 02 Fax: +33 (0)1 48 91 21 21...
