Nr.
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
Systemwartungsschalter
Position
S1
S2
S3
S4
S5
S6
6
Kapitel 1 Beschreibung der Komponenten
Beschreibung
Lüfteranschluss 1
HPE Smart Storage Battery-Anschluss
Speicher-Notstromanschlüsse
GPU-Netzanschlüsse
Interner USB 2.0-Anschluss
Interner USB 3.0-Anschluss
Systemwartungsschalter
Lüfteranschluss 2
Systembatterie/-akku
NMI-Sockel
MicroSD-Steckplatz
Dedizierter iLO-Port-Anschluss
Steckplatz 6, PCIe3 x8 (8, 4, 1) für Prozessor 1
Steckplatz 5, PCIe3 x16 (16, 8, 4, 1) für Prozessor 1
Steckplatz 4, PCIe3 x8 (8, 4, 1) für Prozessor 1
Steckplatz 3, PCIe3 x16 (16, 8, 4, 1) für Prozessor 2
Steckplatz 2, PCIe3 x8 (8, 4, 1) für Prozessor 1
Steckplatz 1, PCIe3 x8 (8, 4, 1) für Prozessor 2
Standardeinstellung
Aus
Aus
Aus
Aus
Aus
Aus
Funktion
Aus = iLO 4-Sicherheit ist aktiviert.
Ein = iLO 4-Sicherheit ist deaktiviert.
Aus = Die Systemkonfiguration kann
geändert werden.
Ein = Die Systemkonfiguration
ist gesperrt.
Reserviert
Reserviert
Aus = Das Kennwort für den
Systemstart ist aktiviert.
Ein = Das Kennwort für den
Systemstart ist deaktiviert.
Aus = Keine Funktion
Ein = ROM sieht die
Systemkonfiguration als ungültig an.
