(152) AP620A BUILT-IN ELECTRIC PUMP ENGLISH 4.875" X 7.25" 05/14/2014
6. Lie down on the airbed to test the firmness.
7. If the sleeping surface is too hard, adjust the firmness
by turning the control dial counterclockwise gradually
until air starts to exit through the air passage. See
Fig (6). Turn the control dial fully clockwise when the
desired firmness is achieved. See Fig (7). If the airbed
becomes too soft repeat step #3 thru #7 as necessary.
8. Disconnect the AC line cord from the wall socket,
place it inside the cord compartment and close the
cover.
IMPORTANT NOTE
Proper inflation of the airbed.
The ambient temperatures of air have an effect on the airbed internal pressure. At low ambient
temperature the air will contract within the airbed and the airbed will feel softer: add air as necessary.
At high ambient temperature the air within the airbed will expand significantly and the airbed will
become hard and may burst: release air to avoid damage to the airbed or to soften the feel. Do not
expose the airbed to extreme temperatures (hot or cold).
Air inside of bed may expand and contract with varying temperature leading to reduce pressure
inside of the bed. If this occurs, simply add more air using the pump to achieve desired firmness. If
puncture occurs, please refer to instruction. Repair kit/patch is enclosed.
Stretching is a natural characteristic of new vinyl. During initial use, the airbed may become soft and
require additional inflation to maintain desired firmness. This is normal for the first few days of use.
Dimensions shown are approximate and will vary due to the vinyl temperature and the air
temperature.
In no event shall Intex, their authorized agents or employees be liable for damages (such as
pin holes) to the airbed caused by negligence, ordinary wear and tear, abuse and
carelessness, or external forces.
DEFLATION
1. Open line cord compartment cover. See Fig (1).
2. Plug in the AC line cord into an AC electrical outlet. See Fig (2).
3. Turn the control dial counterclockwise until arrow points to deflation mark (
Fig (8).
FIG (8) FIG (9)
4. Press "I" to switch ON. See Fig (4).
5. When the airbed is completely deflated, begin rolling the airbed from the foot of the
airbed towards the head of the airbed where the pump is located. See Fig (9).
6. When all air is removed from the airbed, press "O" to switch OFF. See Fig (5).
7. Turn the control dial fully clockwise. See Fig (10).
8. Disconnect the AC line cord from the wall socket, place it inside the cord
compartment and close the cover.
SAVE THESE INSTRUCTIONS
Page 3
152
FIG (6)
FIG (7)
). See
FIG (10)
(152) AP620A BUILT-IN ELECTRIC PUMP ENGLISH 4.875" X 7.25" 05/14/2014
INFLATION OPTION
1. If electrical power is not available then a conventional foot
or manually operated air pump can be connected to the
control dial valve for inflation. See Fig (11).
2. Turn the control dial clockwise until arrow points to the
inflation mark ( ).
3. Insert air pump nozzle to the control dial
valve to inflate the airbed.
IMPORTANT
Inflate only with a low pressure inflator. Do not over inflate. Fill with cold air only.
STORAGE
1. Deflate the airbed following the "DEFLATION" instructions.
2. Turn the control dial counterclockwise until arrow points to deflation mark (
Fig (8).
3. Make sure the airbed is clean and dry.
4. Lay bed flat with sleeping surface facing upwards and follow the folding steps on Figs
(12 - 16). Fold the airbed loosely and avoid sharp bends, corners and creases which can
damage the airbed.
FIG (12)
INTEX
INTEX
FIG (15)
INTEX
5. Turn the control dial fully clockwise. See Fig (10).
INTEX
INTEX
6. Place the airbed inside the storage bag and store in a dry, cool storage location.
