Total mirror radiators have an advanced system control with a touch-screen keyboard and with some indica-
tor lights (LED lights) which show the set mode.
Any change in the settings is pointed out by some acoustic sounds.
When the radiator is connected to electricity, all LEDs light up for 2 seconds and you hear a long acoustic
sound, then L1 and L8 keep lighting up.
If you want to heat the room at low temperature, please touch T2. In this way green LED L2 and red LED
L7 turn on and you hear a beep. When the surface of the radiator reaches the set point temperature, L7 turns
off and it ciclically turns on again in order to keep the set poin temperature.
If you want to heat the room at middle temperature, please touch T3. In this way green LED L3 and red
LED L7 turn on and you hear a beep. When the surface of the radiator reaches the set temperature, L7 turns
off and it ciclically turns on again in order to keep the set temperature.
If you want to heat the room at high temperature, please touch T4. In this way green LED L4 and red
LED L7 turn on and you hear a beep. When the surface of the radiator reaches the set temperature, L7 turns
off and it ciclically turns on again in order to keep the set temperature.
If you want the maximum temperature for a restricted period (2 hours), please touch T5, L5 and L7 turn on.
The radiator will work to maximum temperature for 2 hours, then it automatically returns to its previous
mode.
If you want to lock the keyboard and prevent changes to settings, please touch T6 for more than 5 seconds.
You will hear 4 beeps indicating that the keyboard is locked. Now if a key is touched, L6 flashes for 2-3
seconds but the settings won't be changed. T1 is the only key that keeps working and it allows you to put in
stand-by the radiator.
To unlock the keyboard you need to touch T6 for 5 seconds. The radiator will sound 4 times to confirm the
operation.

5. REMOTE CONTROL

Total Mirror radiators are supplied with an infrared remote control which allows you to manage environ-
ment temperature and to set all different programs.
When S1 sensor receives the information, L8 flashes and keeps lighting up to indicate that the radiator has
been set. For a good communication you need to put the remote control towards the receiver.
The distance between remote control and receiver has not to exceed 7m.

5.1 INSTALLING BATTERIES

Remover the cover placed on the back of the remote control.
Insert two alkaline batteries AAA 1.5 V. Note the correct polarity when inserting the batteries. Put the cover
in place.
Remember to take used batteries to battery collection points so they can be recycled.
