4.1 Touch-screen keyboard
Icons and functions (Fig. 7)
T1 STAND-BY.........................................................................................L1
T2 Heating at low temperature (40° ca).................................................L2
T3 Heating at middle temperature (50°ca)...............................................L3
T4 Heating at maximum temperature (70°ca) .........................................L4
T5 2h Boost at maximum temperature......................................................L5
T6 Child-proof keyboard lock....................................................................L6
L7 The red light indicates that the radiator is heating
L8 The radiator is connected to the electricity supply
S1 infrared sensor for remote control
L1
L2
L3
L4
L5
L6
S1
7
T1
T2
T3
T4
T5
T6
L7 L8
