54
Do not remove the battery by yourself! Under no circumstances
should the cover at the bottom of the down tube be opened.
Only trained personnel should carry out maintenance or repairs
on the installed drive system. Carrying out maintenance or repairs may
result in danger to life due to live parts such as cables and contacts.
Furthermore, the drive system is being protected against moisture by a
special sealing technology, which is why warranty obligations become inva-
lid if the down tube is being opened without the approval by Coboc.
Reach: The range of your Coboc e-bike is heavily dependent on various
influencing factors and can therefore fluctuate. These include the following
factors, among others: the type of surface, incline/slope of the route, wind
conditions, tire characteristics, air pressure, driver weight, cadence, driving
speed and temperature. The settings of the drive parameters also have an
impact on the range of your Coboc e-bike. Information about the Coboc
app and the setting of the individual drive parameters can be found here:
www.coboc.biz/en/the-coboc-app/.
With a fully charged battery and on level terrain, preset mode 1 (blue
LEDSs) can be used to achieve approx. 75-110 km. When driving on as-
phalt roads, a low tire pressure can increase the rolling resistance and thus
reduce the range. Headwinds or hilly terrain will also have a negative im-
pact on the range. Increasing the drive parameters via the Coboc app will
express itself in stronger support but in return in a shorter range. A higher
total weight will also reduce the range of your Coboc e-bike. If you drive
over 25km/h in return, the motor support is switched off and you ride your
e-bike like a normal e-bike. This increases the remaining range accordingly.
On hot days (battery temperature of more than 60° C) the battery turns its-
elf off for safety reasons. After that, it has to cool down before you are able
to use it again. If your e-bike has not been turned on or charged for more
than 30 days, it automatically sets itself into a deep sleep mode in order to
save battery power. If in deep sleep mode, your Coboc e-bike can not be
turned on. However, you can reactivate it first by plugging in the charger.
Battery & Charger
Battery level is displayed on the user interface. Up to five LEDs light up
after turning on the Coboc e-bike. They are split up as follows:
5 LEDs are lit up in blue
4 LEDs are lit up in blue
3 LEDs are lit up in blue
2 LEDs are lit up in blue
1 LEDs are lit up in blue
If more than one LED is flashing red this indicates an error within
the drive system. See chapter "Error codes" for more insight.

Charging the battery

The ideal ambient temperature for battery charging is somewhere bet-
ween 5ºC and 25ºC. At temperatures between 0ºC and 40ºC electronics
disable charging, in order to protect the battery from getting damaged.
Please refrain from using any charger other than the one included
in your delivery from Coboc or chargers authorized by Coboc.
Modern lithium-ion batteries require chargers that are perfectly
matched, as everything else could lead to the battery catching fire or even
exploding.
Make sure to check the charger for any external damage (case,
plug or cables). Under no circumstances should you use a
damaged or faulty charger.
The charging socket is situated at the bottom side of the top tube. You can
only insert the plug in one direction. Socket and plug are magnetic and
stay attached if connected correctly.
battery level of 80 % to 100 %
g
battery level of 60 % to 80 %
g
battery level of 40 % to 60 %
g
battery level of 20 % to 40 %
g
battery level of 1 % to 20 %
g
