The A-weighted emission sound pressure level at the driver's ears
is less than 70 dB(A).
Coboc, such as our dealers, assumes no liability for any use other than the
one intended, especially regarding non-compliance with the information
given in this user manual.

Before every ride

Make sure your Coboc e-bike is ready for operation and that it is adjusted
to your body height. Saddle height and handlebar position should be
adjusted properly. Your saddle should be set to a comfortable and safe
height.
Choosing a frame size that does not suit your height or a
defective adjustment may lead to loss of control and ultimately
may lead to slips or crashes which again may lead to serious
injuries and damage. If you have problems with picking the right frame size
or how to properly adjust your Coboc e-bike, please refer to your local
Coboc dealer.

Adjusting the saddle height

The seat post may under no circumstances be put higher than the
minimum depth of insertion. A mark at the seat post signals the
designated minimum depth of insertion. Pulling the seat post out
too far may result in crashes and serious damage to you and your e-bike.
By using your Coboc e-bike when the minimum insertion depth is
undershot, the Coboc manufacturer's warranty for any resulting damage to
your e-bike is void.
You may position your saddle in three different directions. First, make sure
that the seat post clamping at the frame and the saddle clamping at the
seat post are firmly tightened. Sit on the saddle and put one foot on the
pedal while posting your other foot on the ground. Now use your heel to
carefully tread the pedal until the crank arm is in line with the saddle tube.
If you are standing on the pedal but your leg is not fully extended, this
means that the saddle is probably too low. Vice versa if you have to reach
for the pedal or if you have to tip your pelvis forward, that means that your
Before every Ride
saddle is positioned too high. If needed, you can loosen the seat post
clamping at the frame, adjust the correct saddle height and tighten the
clamping again.
Make sure that the saddle is in line with the top tube of your e-bike. Again,
you may loosen the seat post clamping, in order to move the saddle left
and right, before tightening it again. It is also possible to change the sadd-
le tilt relative to the top tube. Just loosen the clamping at the seat post,
adjust to your needs and tighten again.
Align the grips
Ergonomic Ergon GA30 grips are installed on your Iseo. With their
enlarged contact surface on the ball of the hand, they effectively prevent
the wrists from kinking and enable fatigue-free riding. So that they can
perform their function optimally, they must be mounted so that the contact
surface is horizontal.
Please bear in mind the permissible torque for all these steps (s.
table Tightening torque) and make sure that all screw fittings are
tightened before using your Coboc e-bike or sitting on your sadd-
le to adjust it again.
Regular monitoring
Make sure that the lighting system on your Coboc e-bike works in the front
and in the back.
You should be able to reach both braking levers without any problems.
Also make sure to know which braking lever applies to which brake. As
